Mean Well PLM-12E-350, 350mA Constant Current with PFC - Terminal Block
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PLM-12E-350, 350mA Constant Current with PFC - Terminal B...
The PLM-12E is a 12W Mean Well DIN rail power converter with a 145mm profile (input range: 110~295VAC, operating temperature: -30~+50℃).
Key Features
- ✓ 145mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 110~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12(for Blank type only); ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14,GB19510.1 (for E type only) ,EAC TP TC 004, IP30
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLM Series
-
Power Rating12.6 Watt
-
Output Voltage42 Volt
-
Rated Current0.35 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~50°C
-
Warranty2 Year
-
Length5.71 in
-
Width1.5 in
-
Height0.87 in
-
Weight0.28 lb
::specification::
Frequently Asked Questions
What type of LED driver is the Mean Well PLM-12E-350?
The PLM-12E-350 is a constant current LED driver rated at 350mA. It delivers up to 42V output with a 12.6W power rating. This model is intended for loads that are specified for constant current operation rather than fixed-voltage output.
What kinds of applications is the PLM-12E-350 suited for?
This model is suited to LED lighting applications that require a 350mA constant current driver. Its compact plastic case, Class II design, and free-air convection cooling make it a practical choice for enclosed lighting products and general indoor commercial use. It is best matched to applications that stay within its 12.6W and 42V limits.
Is the PLM-12E-350 a dimmable LED driver?
No. The listed dimming control for this model is none, so it is a non-dimming driver. If your project requires brightness control, you would need a different driver designed with a supported dimming interface.
What input range does the PLM-12E-350 support?
This E-version model is specified for an AC input range of 180 to 295VAC, with a DC input range of 254 to 417VDC. That makes it appropriate for higher-voltage mains environments within that range. It also includes built-in active PFC as part of its design.
Can I use the PLM-12E-350 with any LED product?
Not with every LED product. It should be used with LED loads that require 350mA constant current and operate within the driver's available output range up to 42V. It is not the right choice for products that call for a constant voltage power supply.
What environmental conditions is the PLM-12E-350 designed for?
The PLM-12E-350 is rated for operation from -30°C to 50°C. It uses free-air convection cooling and has an IP30 plastic enclosure, so it is generally intended for protected indoor environments rather than exposed outdoor conditions. The isolated plastic case also supports Class II use.
