Mean Well RSP-3000-24 Power Supply 3000W 24V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RSP-3000-24 Power Supply 3000W 24V
The RSP-3000 is a 3000W Mean Well power converter (input range: 180~264VAC).
Key Features
- ✓ Input voltage range: 180~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSP Series
-
Power Rating3000 Watt
-
Output Voltage24 Volt
-
Rated Current125 Ampere
-
Input Voltage180V~264V
-
No of Output1
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty5 Year
-
Length10.94 in
-
Width7 in
-
Height2.5 in
-
Weight8.82 lb
::specification::
Frequently Asked Questions
What industrial systems is the RSP-3000-24 designed to power?
With 3000W at 24V and 125A output, the RSP-3000-24 is suited for large-scale industrial motor drives, high-power automation panels, and multi-axis CNC systems running on a 24V DC bus. Its 5-year warranty and UL/CE/TÜV certifications make it appropriate for regulated industrial deployments.
What are the environmental limits of the RSP-3000-24?
The RSP-3000-24 operates from -20°C to +70°C ambient. It is designed exclusively for indoor enclosed installations; no IP rating is assigned for wet or outdoor use.
How does the RSP-3000-24 compare to the RSP-2400-24?
The RSP-2400-24 and RSP-3000-24 share the same 278.0 × 177.8 × 63.5 mm form factor and both require 180-264VAC input. The RSP-2400-24 delivers 2400W at 100A; the RSP-3000-24 increases output to 3000W at 125A. Both offer 2+1 active current sharing and up to 91.5% efficiency. The RSP-3000-24 weighs 4.0 kg vs. 3.3 kg for the RSP-2400-24.
Can multiple RSP-3000-24 units be paralleled?
Yes. The RSP-3000-24 supports 2+1 active current sharing, allowing up to two units in parallel with a third for redundancy, reaching a combined output of 250A at 24V.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other RSP-3000 Models
2 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well RSP-3000-48 Power Supply 3000W 48V | 3000W | 48V | 62.5A | Indoor | $505.55 | View |
| Mean Well RSP-3000-12 Power Supply 2400W 12V | 2400W | 12V | 200A | Indoor | $531.51 | View |
