Mean Well RS-150-12 Power Supply 150W 12V
The RS-150 is a 150W Mean Well DIN rail power converter with a 199mm profile (input range: 88~132VAC).
Key Features
- ✓ 199mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 88~132VAC
- ✓ Cooling by free air convection — no minimum load required
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-~ EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating150 Watt
-
Output Voltage12 Volt
-
Rated Current12.5 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length7.83 in
-
Width3.86 in
-
Height1.5 in
-
Weight1.54 lb
::specification::
Frequently Asked Questions
Can I use the RS-150-12 for a 12V industrial control panel with multiple loads?
Yes, this model is a constant-voltage 12V supply rated for 12.5A and 150W. That makes it suitable for larger control panels, distributed 12V loads, and automation assemblies that need more headroom than small 12V supplies.
Is the RS-150-12 a good choice for 12V CCTV, access control, or alarm hardware?
It can be a fit for centralized 12V security and control hardware when the total demand stays within 12.5A. With 150W available, it supports higher combined 12V loads than compact power supplies in the same series.
Can this power supply run 12V automation peripherals such as relays, controllers, and interface modules?
Yes, it is designed for constant-voltage 12V output and can support multiple 12V automation peripherals on one supply. The practical limit is the unit's 150W maximum output and 12.5A current rating.
Is the RS-150-12 suitable for larger 12V LED or signage systems?
It is often a better fit for larger 12V constant-voltage loads because it provides substantially more output than the lower-wattage 12V RS models. Buyers should size the total load against the published 150W and 12.5A ratings.
Can the RS-150-12 handle demanding indoor environments?
The operating temperature range is -25°C to +70°C, which is broader than the smaller 15W models in this set. The provided specs do not list an IP rating, so it is best used in protected indoor enclosures rather than directly exposed outdoor environments.
How does the RS-150-12 compare with other 12V RS series models?
The listed 12V siblings are RS-15-12 at 15.6W and 1.3A, RS-25-12 at 25.2W and 2.1A, RS-35-12 at 35W and 3A, RS-50-12 at 50.4W and 4.2A, RS-75-12 at 72W and 6A, RS-100-12 at 102W and 8.5A, and RS-150-12 at 150W and 12.5A. RS-150-12 is the highest-output 12V model listed in this sibling group.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other RS-150 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well RS-150-24 Power Supply 150W 24V | 156W | 24V | 6.5A | Indoor | $26.69 | View |
| Mean Well RS-150-15 Power Supply 150W 15V | 150W | 15V | 10A | Indoor | $29.34 | View |
| Mean Well RS-150-5 Power Supply 150W 5V | 130W | 5V | 26A | Indoor | $29.34 | View |
| Mean Well RS-150-48 Power Supply 150W 48V | 158.4W | 48V | 3.3A | Indoor | $29.42 | View |
| Mean Well RS-150-3.3 Power Supply 150W 3.3V | 99W | 3.3V | 30A | Indoor | $29.33 | View |
