Mean Well RS-25-12 Power Supply 25W 12V
The RS-25 is a 25W Mean Well DIN rail power converter with a 78mm profile (input range: 125~373VDC).
Key Features
- ✓ 78mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection — no minimum load required
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368- EAC TP TC 004,CCC GB4943.1,BSMI CNS14336-`
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating25.2 Watt
-
Output Voltage12 Volt
-
Rated Current2.1 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length3.07 in
-
Width2.01 in
-
Height1.1 in
-
Weight0.44 lb
::specification::
Frequently Asked Questions
Can I use the RS-25-12 for a small 12V control or automation device?
Yes, if the load requires constant-voltage 12V and draws no more than 2.1A. With 25.2W available, it is aimed at smaller 12V control and automation loads rather than higher-power equipment.
Is the RS-25-12 suitable for compact embedded systems that run on 12V DC?
It is a constant-voltage 12V supply with up to 2.1A output current. That makes it a practical fit for compact embedded systems whose total demand stays within 25.2W.
Can this model power a low-power 12V industrial sensor or interface module?
It can power 12V industrial electronics as long as the total load is at or below 2.1A and 25.2W. The compact 78.0 × 51.0 × 28.0 mm size also supports space-constrained equipment layouts.
How do I know whether the RS-25-12 is too small for my 12V load?
Use it only with constant-voltage 12V equipment that stays within 2.1A and 25.2W. If your load needs more than either of those values, you need a higher-capacity 12V model.
Is the RS-25-12 for indoor use only, or can it handle wider environmental conditions?
Its operating temperature range is -20°C to +70°C, which supports a broad indoor industrial temperature span. The provided specs do not include an IP rating, so outdoor exposure is not established by this data.
How does the RS-25-12 compare with other 12V RS series options?
The listed 12V RS models are RS-15-12 at 15.6W and 1.3A, RS-25-12 at 25.2W and 2.1A, RS-35-12 at 35W and 3A, RS-50-12 at 50.4W and 4.2A, RS-75-12 at 72W and 6A, RS-100-12 at 102W and 8.5A, and RS-150-12 at 150W and 12.5A. RS-25-12 sits near the low-power end of that 12V range.
