Mean Well RS-25-24 Power Supply 25W 24V
The RS-25 is a 25W Mean Well DIN rail power converter with a 78mm profile (input range: 125~373VDC).
Key Features
- ✓ 78mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection — no minimum load required
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368- EAC TP TC 004,CCC GB4943.1,BSMI CNS14336-`
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating26.4 Watt
-
Output Voltage24 Volt
-
Rated Current1.1 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length3.07 in
-
Width2.01 in
-
Height1.1 in
-
Weight0.44 lb
::specification::
Frequently Asked Questions
Can I use the RS-25-24 for a 24V PLC accessory or industrial control circuit?
Yes, if the connected 24V load stays within 1.1A and 26.4W. That makes it suitable for lower-power PLC accessories, control circuits, and other 24V automation devices that do not exceed that output limit.
Is the RS-25-24 a good fit for 24V sensors, relays, or small automation peripherals?
It is intended for 24V constant voltage loads and can supply up to 1.1A. For small automation peripherals with modest current demand, that output range is often appropriate as long as the total load remains under 26.4W.
Can this 24V power supply be used in compact industrial or embedded equipment?
It is sized for compact equipment at 78.0 x 51.0 x 28.0 mm and weighs 0.2 kg. The combination of 24V output, 26.4W capacity, and 88-264VAC input suits space-constrained equipment needing a low-power AC-DC supply.
Would the RS-25-24 work for a small 24V DC automation subsystem in a control enclosure?
It can support a small 24V subsystem if the total demand does not exceed 1.1A at 24V. Its constant voltage output is intended for equipment designed to run from a regulated 24V DC source.
Can the RS-25-24 be used in hot or cold indoor industrial environments?
The specified operating temperature range is -20 degrees C to +70 degrees C, so the temperature envelope is defined for demanding indoor conditions. No IP rating is listed, so the provided specs do not establish outdoor or water-exposure suitability.
How does the RS-25-24 compare with the other RS-25 output versions?
The RS-25 family includes RS-25-3.3 at 19.8W, 3.3V, 6A; RS-25-5 at 25W, 5V, 5A; RS-25-12 at 25.2W, 12V, 2.1A; RS-25-15 at 25.5W, 15V, 1.7A; RS-25-24 at 26.4W, 24V, 1.1A; and RS-25-48 at 27.36W, 48V, 0.57A. The 24V model sits in the middle of the voltage range and provides lower current than the lower-voltage versions.
