Mean Well RS-25-5 Power Supply 25W 5V
The RS-25 is a 25W Mean Well DIN rail power converter with a 78mm profile (input range: 125~373VDC).
Key Features
- ✓ 78mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection — no minimum load required
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368- EAC TP TC 004,CCC GB4943.1,BSMI CNS14336-`
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating25 Watt
-
Output Voltage5 Volt
-
Rated Current5 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length3.07 in
-
Width2.01 in
-
Height1.1 in
-
Weight0.44 lb
::specification::
Frequently Asked Questions
Can I use the RS-25-5 to power a 5V single-board computer or embedded controller?
Yes, if the equipment needs a 5V constant voltage supply and the total load does not exceed 5A or 25W. That makes it suitable for many 5V embedded controllers, processor boards, and support electronics within that power budget.
Is the RS-25-5 suitable for 5V industrial logic, I/O, or communications electronics?
It is intended for 5V constant voltage loads and can deliver up to 5A. For industrial logic or communications electronics designed for a regulated 5V rail, it is a fit if the total demand stays within 25W.
Can this power supply run multiple low-power 5V modules in one enclosure?
It can, provided the combined load remains at or below 5A and 25W. Its compact 78.0 x 51.0 x 28.0 mm size also helps when several low-power modules share limited enclosure space.
Would the RS-25-5 work in compact automation or test equipment that needs a 5V rail?
It is a reasonable choice for compact automation or bench equipment that needs 5V DC and stays within 5A output current. The 88-264VAC input range also supports use across common global AC supply ranges.
Can the RS-25-5 be used in outdoor or washdown environments?
The operating temperature range is specified as -20 degrees C to +70 degrees C, so the thermal range is defined. No IP rating is listed, which means the provided specs do not confirm protection for outdoor exposure, washdown, or dust-heavy environments.
How does the RS-25-5 compare with the other RS-25 models?
The RS-25 lineup includes RS-25-3.3 at 19.8W, 3.3V, 6A; RS-25-5 at 25W, 5V, 5A; RS-25-12 at 25.2W, 12V, 2.1A; RS-25-15 at 25.5W, 15V, 1.7A; RS-25-24 at 26.4W, 24V, 1.1A; and RS-25-48 at 27.36W, 48V, 0.57A. Compared with the higher-voltage versions, the 5V model provides higher output current at 5A.
