Mean Well RSP-200-2.5 Power Supply 100W 2.5V
The RSP-200 is a 200W Mean Well DIN rail power converter with a 215mm profile (input range: 88~264VAC).
Key Features
- ✓ 215mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 88~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: AS/NZS 60950.1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSP Series
-
Power Rating100 Watt
-
Output Voltage2.5 Volt
-
Rated Current40 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.18 in
-
Weight1.59 lb
::specification::
Frequently Asked Questions
What applications require a 2.5V supply like the RSP-200-2.5?
The RSP-200-2.5 provides 2.5V at 40A (100W) and is intended for DRAM termination supplies, low-voltage FPGA core rails, high-current logic termination in embedded systems, and specialized DSP board power planes. At 40A the RSP-200-2.5 can power multiple boards simultaneously drawing 2.5V. The 88–264VAC input supports all standard mains voltages.
Why does the RSP-200-2.5 deliver only 100W despite the RSP-200 platform rating?
The RSP-200-2.5 is limited to 100W because the 40A current ceiling of the platform, when multiplied by 2.5V, yields 100W (2.5V × 40A). The RSP-200 model number reflects the platform's target wattage at higher voltages; at 2.5V the available wattage is constrained by the current limit.
How does the RSP-200-2.5 compare to the RSP-200-3.3 and RSP-200-4?
The RSP-200-2.5 delivers 2.5V/40A/100W. The RSP-200-3.3 delivers 3.3V/40A/132W. The RSP-200-4 delivers 4V/40A/160W. All share the same 40A maximum current and 215.0 × 115.0 × 30.0 mm chassis. Total wattage increases with voltage while current remains fixed at 40A.
Is the RSP-200-2.5 suitable for operation in warm server or networking enclosures?
The RSP-200-2.5 is rated from -30°C to +70°C ambient. For warm server or telecommunications cabinets, ensure ambient temperature at the unit stays at or below +70°C. No IP rating is specified; the unit requires an appropriate enclosure for the environment.
What certifications does the RSP-200-2.5 carry?
The RSP-200-2.5 holds BSMI, CB, CCC, CE, EAC, c_rcm, TÜV, and UL certifications, including CCC (China) and c_rcm (Australia/NZ), providing broad global market coverage.
