Mean Well SPA01A-15 DC-DC Converter - 1W - 9~18V in 15V out
The SPA01A is a 1W Mean Well power converter (input range: 9~18VDC, operating temperature: -40~+90℃).
Key Features
- ✓ Input voltage range: 9~18VDC
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: 20% ~ 90% RH non-condensing -40 ~ +105 ± 0.05% / , 10 ~ 95% RH ℃ (0 ~ 50 ℃ ℃ ) 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSPA Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage9V~18V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty2 Year
-
Length0.69 in
-
Width0.44 in
-
Height0.31 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SPA01A-15 for a low-power 15V analog or instrumentation circuit?
Yes, it is suited to small 15V constant-voltage circuits used in instrumentation, signal processing, or industrial electronics. Its output is limited to 15V at 0.07A and 1W total power, so it should be used only for low-power sections.
Is the SPA01A-15 appropriate for powering a 15V reference or interface stage in automation equipment?
This converter can serve a 15V reference, interface, or auxiliary stage where the input source is within 9-18VAC. The output capacity is 1W with 0.07A maximum, which aligns with compact board-level functions rather than higher-load devices.
Would the SPA01A-15 work for a compact embedded system that needs a small 15V rail?
It is a reasonable choice when the embedded design needs a constant 15V rail for a light-duty circuit block. With 15V output and 0.07A maximum current, it is best for low-power control or measurement electronics.
Can this model be used in equipment exposed to very low or very high temperatures?
The specified operating range is -40°C to +90°C, so the temperature rating is broad for industrial equipment use. However, no IP rating is provided, so the listing does not confirm outdoor or moisture-exposed use by itself.
What is the difference between the SPA01A-15 and the other SPA01A versions?
The listed SPA01A siblings all share a 1W platform, but their outputs differ. SPA01A-05 is 5V and 200A, SPA01A-12 is 12V and 0.08A, and SPA01A-15 is 15V and 0.07A.
