Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SPA01B-12 DC-DC Converter - 1W - 18~36V in 12V out

$8.16 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

"

Features

  • Wide 2:1 DC input range
  • In/out capacitance 1000pF
  • Protections: Short circuit / Overload
  • 1500 VDC I/O isolation
  • Built-in EMI filter without external components
  • Cooling by free air convection
  • 100% full load burn-in test
  • Low cost
  • High relibility
  • 2 years warranty

Specifications

  • Brand
    Mean Well
  • Series
    SPA Series
  • Power Rating
    1 Watt
  • Output Voltage
    12 Volt
  • Rated Current
    0.08 Ampere
  • Input Voltage
    18V~36V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CE,EAC,EMC,FCC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~90°C
  • Warranty
    2 Year
  • Length
    0.69 in
  • Width
    0.44 in
  • Height
    0.31 in
  • Weight
    0.01 lb
