Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SPA01B-05 DC-DC Converter - 1W - 18~36V in 5V out
Description
Description
Features
- Wide 2:1 DC input range
- In/out capacitance 1000pF
- Protections: Short circuit / Overload
- 1500 VDC I/O isolation
- Built-in EMI filter without external components
- Cooling by free air convection
- 100% full load burn-in test
- Low cost
- High relibility
- 2 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSPA Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty2 Year
-
Length0.69 in
-
Width0.44 in
-
Height0.31 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can the SPA01B-05 be used for a low-power 5V logic or controller circuit in industrial equipment?
Yes, this model is intended for low-power 5V constant-voltage loads supplied from an 18-36VAC input range. It is rated at 1W total power with a listed 5V, 200A output specification, so buyers should size the application to the published product specs.
Is the SPA01B-05 suitable for embedded electronics that need a compact 5V auxiliary rail?
It is suitable where an embedded board needs a small 5V auxiliary supply from an 18-36VAC source. The unit is physically compact at 17.4 × 11.1 × 7.75 mm and is designed as a constant-voltage 5V converter.
Can I use this converter for a 5V monitoring or signal-processing section inside an automation panel?
Yes, it can fit a small 5V monitoring or signal-processing section where the converter's published 1W rating matches the load requirement. It is intended for low-power internal electronics rather than larger 5V equipment loads.
Is the SPA01B-05 rated for outdoor or temperature-extreme locations?
Its operating temperature range is -40°C to +90°C, which supports use in equipment exposed to wide temperature variation. No IP rating is listed, so the product data does not by itself confirm suitability for outdoor or wet-location exposure.
How does the SPA01B-05 compare with the other SPA01B models?
The SPA01B family shown here shares the same 1W series format with different outputs. SPA01B-05 is listed at 5V and 200A, SPA01B-12 at 12V and 0.08A, and SPA01B-15 at 15V and 0.07A.
Other SPA01 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SPA01C-15 DC-DC Converter - 1W - 36~75V in 15V out | 1W | 15V | 0.06A | Indoor | $8.18 | View |
| Mean Well SPA01C-12 DC-DC Converter - 1W - 36~75V in 12V out | 1W | 12V | 0.08A | Indoor | $7.97 | View |
| Mean Well SPA01C-05 DC-DC Converter - 1W - 36~75V in 5V out | 1W | 5V | 0.2A | Indoor | $8.18 | View |
| Mean Well SPA01B-15 DC-DC Converter - 1W - 18~36V in 15V out | 1W | 15V | 0.06A | Indoor | $8.18 | View |
| Mean Well SPA01B-12 DC-DC Converter - 1W - 18~36V in 12V out | 1W | 12V | 0.08A | Indoor | $8.16 | View |
| Mean Well SPA01A-15 DC-DC Converter - 1W - 9~18V in 15V out | 1W | 15V | 0.06A | Indoor | $8.18 | View |
| Mean Well SPA01A-12 DC-DC Converter - 1W - 9~18V in 12V out | 1W | 12V | 0.08A | Indoor | $8.18 | View |
| Mean Well SPA01A-05 DC-DC Converter - 1W - 9~18V in 5V out | 1W | 5V | 0.2A | Indoor | $8.08 | View |
