Mean Well SHP-30K-380 30KW High Efficiency Power Supply 55V Out 79A

The Mean Well SHP-30K-380 is a 30,000W high-efficiency digital power supply delivering 380V DC at up to 79A. Digital control gives tight regulation and full monitoring, and efficiency above 96% keeps heat and running cost down at this power level.

It runs from a three-phase 340~530VAC supply with a power factor above 0.98 at full load, operates from -30°C to 70°C and carries CB, CE, EAC and EN approvals, and includes constant-current limiting, over-voltage and over-temperature protection. Backed by a 5-year warranty.

Key Features

• ✓3ψ 3-wire / △ or Y 340~530VAC or 3ψ 4-wire / Y 340-530VAC
• ✓High efficiency up to 97%
• ✓2U high 19"-inch rack with forced air cooling
• ✓Built-in CANBus/Optional PMBus/MODBus-RTU/RS-485 protocol
• ✓Output voltage and constant current level programmable
• ✓active current sharing up to 12 units(285KW) and more
• ✓Built-in remote ON-OFF control / Auxiliary power / Alarm signal / Fan faill
• ✓Protections: Short circuit / Overload / Over voltage / Over temperature
• ✓Double insulation for 55V model
• ✓5 years warranty

• Brand
  Mean Well
• Series
  Mean Well SHP Series
• Power Rating
  30000 Watt
• Output Voltage
  380 Volt
• Rated Current
  79 Ampere
• Input Voltage
  340V~530V
• No of Output
  1
• Standards Met
  CB,CE,EAC,EN
• Operation Mode
  Constant Voltage
• Operating Temperature
  -30°C~70°C
• Warranty
  5 Year
• Length
  21.26 in
• Width
  16.69 in
• Height
  3.29 in
• Weight
  51.59 lb
