Description
Description
Features
Universal AC input / Full range |
Fully isolated plastic case |
Protections: Short circuit / Over voltage |
Constant current design (C.C. mode) |
IP30 design |
Class 2 power unit / Pass LPS |
Isolation class II, no F.G. |
Cooling by free air convection |
100% full load burn-in test |
Low cost, high reliability |
Suitable for LED lighting and moving sign applications |
2 years warranty |
General Specification
AC input voltage range | 90~264VAC ; 127~370VDC |
AC inrush current | Cold start, 70A at 230VAC |
Overload Range | >105% rated output current |
Protection Type | Hiccup up mode, auto-recovery |
Over voltage protection | 110%~145% rated output voltage |
Withstand voltage | I/P-O/P: 3kVAC |
Working temperature | -30~+70°C (refer to output derating curve) |
Vibration | 10~500Hz, 2G 10 minutes /1 cycle, period for 60 minutes each along X, Y, Z axes |
Safety standards | UL8750 approved; Design refer to IEC61347-1, IEC61347-2-13 |
EMC standards | EN55015, EN61000-3-2 class A , EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 |
Connection Input | UL rated, 18AWGx2C (15cm) |
Connection Output | UL rated, 20AWGx2C (15cm) |
Dimension (LxWxH)(mm) | 77x 40x 29 |
Specifications
Specifications
-
BrandMean Well
-
SeriesAPC Series
-
Power Rating16.8 Watt
-
Output Voltage24 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CE,cUL,EAC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length3.03 in
-
Width1.57 in
-
Height1.14 in
-
Weight0.22 lb
