Mean Well ELG-150-12AB Power Supply | 120W 12V

Q: Can the ELG-150-12AB be used to drive 12V LED strips in an outdoor retail sign cabinet?

The ELG-150-12AB is rated IP65, which protects against water jets and dust but is not submersion-rated. It is appropriate for sign cabinets that shield the driver from direct rain exposure. For unprotected outdoor mounting where direct rain contact is likely, consider the IP67-rated ELG-150-12B instead.

Q: Is the ELG-150-12AB appropriate for a 12V LED strip installation in a hotel corridor with a building-automation dimming system?

Yes. The AB suffix means the driver supports both adjustable output current and 3-in-1 dimming (1–10V, PWM, and resistance). This covers the range of control interfaces used in building-automation and hospitality environments, allowing integration with scene controllers or BMS systems.

Q: How many meters of 12V LED strip can the ELG-150-12AB power?

The driver outputs 120W at 10A. For a 12V strip rated at 14.4 W/m, you can run approximately 8.3 m per driver (120 W ÷ 14.4 W/m). For a denser strip at 24 W/m, that reduces to about 5 m. Always verify the strip's rated power per meter and allow a 10–20% safety margin.

Q: Can the ELG-150-12AB power 12V LED tape used in cove lighting for a restaurant interior?

Yes. With 120W of output at 12V and support for continuous dimming via the built-in 3-in-1 interface, this driver suits restaurant cove lighting where tunable ambient levels are needed for different service periods. The adjustable current also allows fine brightness calibration during the fit-out.

Q: Is the ELG-150-12AB suitable for 12V LED strip lighting in a residential bathroom with steam or humidity?

The IP65 rating provides protection against water spray, which covers steam and humidity in bathroom environments. Avoid direct water contact on the driver body. For shower niches or areas with direct water splash, the IP67 variant would offer additional protection.

Q: Can this driver be used in a commercial office fit-out with 0–10V dimmers controlling 12V LED strip ceiling lights?

Yes. The AB model includes 1–10V dimming support as part of its 3-in-1 interface, which is directly compatible with standard 0–10V commercial dimmers. At 120W and 10A, it provides sufficient power for multi-meter runs of 12V ceiling strip in open-plan office layouts.

Description

Features

100~305VAC wide input range

Built-in active PFC

Protections: Short circuit / Over voltage/Over temperature

No load power consumption <0.5W

High efficiency up to 92%

Suitable for LED lighting and street lighting applications

Cooling by free air convection

100% full load burn-in test

5 years warranty

General Specification

AC input voltage range	100~305VAC;142~431VDC
AC inrush current	Cold start, 65 at 230VAC
DC adjustment range	±10% rated output voltage
Over voltage protection	110%~140% rated output voltage
Setup, rise, hold up time	500ms
Withstand voltage	I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC
Working temperature	-40~+80°C (refer to output derating curve)
Safety standards	UL8750 approved
EMC standards	EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, GB17743,GB17625.1
Dimension (LxWxH)	219x63x35.5
Packing	16pcs / 16.0kg

Specifications

Brand

Mean Well
Series

ELG Series
Power Rating

120 Watt
Output Voltage

12 Volt
Rated Current

10 Ampere
Input Voltage

100V~305V
No of Output

1
Dimming Control

0-10V,10V PWM,Resistance
Standards Met

BSI,CB,CCC,CE,EAC,ENEC,KC,RCM,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

5 Year
Length

8.62 in
Width

2.48 in
Height

1.4 in
Weight

2.09 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can the ELG-150-12AB be used to drive 12V LED strips in an outdoor retail sign cabinet?

The ELG-150-12AB is rated IP65, which protects against water jets and dust but is not submersion-rated. It is appropriate for sign cabinets that shield the driver from direct rain exposure. For unprotected outdoor mounting where direct rain contact is likely, consider the IP67-rated ELG-150-12B instead.

Is the ELG-150-12AB appropriate for a 12V LED strip installation in a hotel corridor with a building-automation dimming system?

Yes. The AB suffix means the driver supports both adjustable output current and 3-in-1 dimming (1–10V, PWM, and resistance). This covers the range of control interfaces used in building-automation and hospitality environments, allowing integration with scene controllers or BMS systems.

How many meters of 12V LED strip can the ELG-150-12AB power?

The driver outputs 120W at 10A. For a 12V strip rated at 14.4 W/m, you can run approximately 8.3 m per driver (120 W ÷ 14.4 W/m). For a denser strip at 24 W/m, that reduces to about 5 m. Always verify the strip's rated power per meter and allow a 10–20% safety margin.

Can the ELG-150-12AB power 12V LED tape used in cove lighting for a restaurant interior?

Yes. With 120W of output at 12V and support for continuous dimming via the built-in 3-in-1 interface, this driver suits restaurant cove lighting where tunable ambient levels are needed for different service periods. The adjustable current also allows fine brightness calibration during the fit-out.

Is the ELG-150-12AB suitable for 12V LED strip lighting in a residential bathroom with steam or humidity?

The IP65 rating provides protection against water spray, which covers steam and humidity in bathroom environments. Avoid direct water contact on the driver body. For shower niches or areas with direct water splash, the IP67 variant would offer additional protection.

Can this driver be used in a commercial office fit-out with 0–10V dimmers controlling 12V LED strip ceiling lights?
