Mean Well ELGC-300-H-ADA Power Supply 300W 5600mA - Adjustable and ...
The ELGC-300-H is a 300W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELGC-H Series
-
Power Rating301 Watt
-
Output Voltage62 Volt
-
Rated Current5.6 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,KC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length9.69 in
-
Width3.03 in
-
Height1.56 in
-
Weight3.2 lb
::specification::
Frequently Asked Questions
Can I use the ELGC-300-H-ADA with constant current LED downlights?
Yes, if the downlight requires 5600mA constant current and its LED load stays within the 29-58V CC range. This is a constant current driver, so it is intended for LED modules designed around current regulation rather than constant voltage input.
Is the ELGC-300-H-ADA a good fit for signage LED modules with dimming control?
It can be, provided the signage modules are built for 5600mA constant current operation and fall within the 29-58V range. This version adds DALI dimming capability, which makes it more suitable where a dimmable constant current driver is required.
Can this driver power a compact LED array that needs DALI dimming?
Yes, if the array is a constant current load rated for 5600mA and operates within 29-58V. The exact number of LEDs depends on the forward voltage of each LED, so the key match is current and total load voltage.
What kind of LED load matches the ELGC-300-H-ADA output range?
The load should be a constant current LED assembly rated at 5600mA, with total forward voltage inside the 29-58V constant current range. LED quantity is not fixed, because the number of LEDs depends on each LED forward voltage.
Is this driver suitable for exposed or harsh environments?
Yes, the IP67 housing is designed for waterproof use, and the operating temperature range is -40°C to +85°C. That combination makes it appropriate for demanding indoor or outdoor environments where moisture and temperature range matter.
