Description
Description
Features
5"x3" compact size |
320W convection, 500W force air 550W peak power (3sec) |
EMI for both Class I & Class II configuration |
-30~+70℃ wide range operating temperature |
No load power consumption<0.5W by PS ON control |
High efficiency up to 94% |
Protections: Short circuit/Overload/Over voltage/Over temperature |
5Vdc standby output, 12Vdc fan supply, Power Good, Power Fail and remote sense |
Operating altitude up to 5000 meters (Note.5) |
LED indicator for power on |
3 years warranty |
General Specification
AC input voltage range | 80 ~ 264VAC; 113 ~ 370VDC |
AC inrush current | COLD START 40A/115VAC |
Leakage current | <0.75mA / 240VAC |
Overload protection | 105 ~ 135% rated output power |
Over-voltage protection | 110%~130% rated output voltage |
Setup, rise, hold up time | 1000ms, 30ms, 10ms |
Withstand voltage | I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC |
Working temperature | -30~+70°C |
Vibration | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
Safety standards | UL62368-1, TUV BS EN/EN62368-1, BS EN/EN60335-1, IEC62368-1, EAC TP TC 004 approved |
EMC standards | UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved |
Connection | I/P: 3 Pin JST B3P-VH, O/P: 4 Pin JST B4P-VH |
Dimension (LxWxH) | 127x76.2x41 |
Packing | 30pcs / 14.8kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating320.4 Watt
-
Output Voltage12 Volt
-
Rated Current26.7 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length5 in
-
Width3 in
-
Height1.61 in
-
Weight1.01 lb
