Mean Well HEP-150-15 Power Supply 150W 15V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-150-15 Power Supply 150W 15V
The HEP-150 is a 150W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC, operating temperature: -60~+80°C).
Key Features
- ✓ 228mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -60~+80°C
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-150 Blank type), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating150 Watt
-
Output Voltage15 Volt
-
Rated Current10 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can I use the HEP-150-15 for a 15V industrial or embedded system?
Yes, if the equipment needs constant voltage 15V output and draws no more than 150W or 10A. The 90-305VAC input, fanless design, and -55°C to +70°C operating range make it suitable for industrial and embedded applications.
Is the HEP-150-15 appropriate for 15V automation equipment in a sealed enclosure?
It can work well for 15V automation loads that need up to 10A from a constant voltage supply. Its fanless construction and high efficiency up to 96% are useful where airflow is limited and enclosure heat matters.
Can this model power 15V monitoring, sensing, or control hardware outdoors?
It can be used where the load requires constant voltage 15V and stays within 150W and 10A. The IP68 rating and -55°C to +70°C operating temperature range make it a stronger option for exposed or wet environments than indoor-only supplies.
Is the HEP-150-15 suitable for outdoor or wet industrial environments?
Yes. This version is listed as IP68 and operates from -55°C to +70°C, so it is intended for harsh indoor or outdoor conditions where strong ingress protection is needed.
How does the HEP-150-15 compare with the other HEP-150 voltage options?
In the HEP-150 series, the 15V models are HEP-150-15 and HEP-150-15A at 150W, 15V, 10A. The other nearby choices are HEP-150-12 and HEP-150-12A at 150W, 12V, 12.5A; HEP-150-24 and HEP-150-24A at 151.2W, 24V, 6.3A; HEP-150-36 and HEP-150-36A at 151.2W, 36V, 4.2A; HEP-150-48 and HEP-150-48A at 153.6W, 48V, 3.2A; and HEP-150-54 and HEP-150-54A at 151.2W, 54V, 2.8A.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other HEP-150 Models
2 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well HEP-150-12A Power Supply 150W 12V | 150W | 12V | 12.5A | IP65 | $87.40 | View |
| Mean Well HEP-150-24A Power Supply 151.2W 24V | 151.2W | 24V | 6.3A | IP65 | $87.40 | View |
