Mean Well HLG-60H-30B Power Supply 60W 30V - Dimmable
Description
Description
Features
| Universal AC input (up to 305VAC) / Full range |
| High efficiency up to 90.5% |
| Built-in active PFC function, PF> 0.9 for 60% of load or higher |
| Protections: Short circuit / Over current / Over voltage / Over temperature |
| IP67 / IP65 design for indoor or outdoor installations |
| Class 2 power unit |
| Output current adjustable through output cable or internal potentiometer |
| Cooling by free air convection |
| Suitable for dry, damp and wet location |
| Suitable for LED lighting and street lighting applications |
| Meet 4kV surge immunity level (IEC61000-4-5) |
| Multiple models for choice: A-Type: IP65 rated. Output voltage and constant current level can be adjusted through internal potentiometer B-Type: IP67 rated and built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance) Blank-Type: IP67 rated. Cable for I/O connection D-Type(option): IP67 rated. Timer dimming function, contact MEAN WELL for details. |
| 7 years warranty |
General Specification
| AC input voltage range | 90~305VAC ; 127~431VDC |
| AC inrush current (max.) | Cold start, 55A at 230VAC |
| DC adjustment range | ±10% rated output voltage (A-Type only) |
| Current adjustment range | 60%~100% |
| Over current protection | 95%~108% constant current limiting, auto-recovery |
| Over voltage protection | 109%~145% rated output voltage |
| Setup, rise, hold up time | 1000ms, 80ms, 16ms at full load and 230VAC |
| Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG:0.5kVAC |
| Working temperature | -40~+70ºC (refer to output derating curve) |
| Safety standards | UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved; Design refer to UL60950-1, EN60950-1, EN60335-1 |
| EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 |
| Connection Input | UL rated, SJTW 18AWGx3C (30cm) |
| Connection Output | A/D/Blank-Type: SVT 18AWGx2C (30cm); B-Type: SVT 18AWGx2C (30cm)+UL2517 18AWGx2C (30cm) |
| Dimension (LxWxH) (mm) | 171x 61.5x 36.8 |
Specifications
Specifications
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating60 Watt
-
Output Voltage30 Volt
-
Rated Current2 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Resistance
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty7 Year
-
Length6.73 in
-
Width2.42 in
-
Height1.45 in
-
Weight1.61 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the HLG-60H-30B to power 30V LED strip lighting outdoors?
Yes. The HLG-60H-30B outputs 30V at up to 2A (60W) and carries an IP67 waterproof rating, meaning it can withstand temporary immersion and heavy rain. Its aluminium casing and -40 to +80 degree Celsius operating range make it reliable for year-round outdoor installations.
Is the HLG-60H-30B suitable for dimmable 30V LED landscape lighting?
Yes. The HLG-60H-30B includes a 1-10V/PWM dimming input, so you can pair with a compatible dimmer to control brightness for garden path lights, bollards, or other 30V landscape fixtures. Its IP67 waterproof rating supports in-ground or fully exposed mounting.
Can I use the HLG-60H-30B to drive 30V LED modules in an outdoor sign?
Yes, as long as the total load does not exceed 60W. The HLG-60H-30B operates in constant-current mode with a CC voltage range of 18-30V, accommodating modules that may operate at slightly lower voltages within that window. The IP67 rating handles rain and moisture typical of exterior signage.
How many meters of 30V LED strip can the HLG-60H-30B drive?
It depends on your strip's power consumption per meter. At 60W output, a strip rated at 12W/m would allow 5 meters (60W / 12W per meter = 5m). A lower-power strip at 6W/m could reach 10 meters. Always check your strip's rated power per meter and keep the total within 60W.
Can the HLG-60H-30B be installed in a location subject to temporary flooding?
Its IP67 rating means it can withstand temporary immersion in water up to 1 meter deep for 30 minutes. This makes it suitable for low-lying enclosures, underground vaults, or areas where standing water may briefly accumulate. The -40 to +80 degree Celsius range also covers freezing conditions.
