Mean Well HLG-60H-36 Power Supply 60W 36V

Name: Mean Well HLG-60H-36 Power Supply 60W 36V
Brand: Mean Well
SKU: HLG-60H-36
Price: 35.82 USD
Availability: InStock

premium quality7 years warrantyaluminium casinghigh efficiency

SKU:

HLG-60H-36

$35.82 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The HLG-60H is a 60W Mean Well power converter (input range: 90~305VAC).

Key Features

✓ Input voltage range: 90~305VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Cooling by free air convection
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: Note.8 SAFETY &
✓ 3 years warranty

Brand

Mean Well
Series

HLG Series
Power Rating

60 Watt
Output Voltage

36 Volt
Rated Current

1.7 Ampere
Input Voltage

90V~305V
No of Output

1
Dimming Control

None
Standards Met

CB,CCC,CE,EAC,PSE,RCM,TUV,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~80°C
Warranty

7 Year
Length

6.73 in
Width

2.42 in
Height

1.45 in
Weight

1.61 lb

Frequently Asked Questions

Can I use the HLG-60H-36 to power 36V LED strip lighting in an outdoor setting?

Yes. The HLG-60H-36 provides 60W at 36V and carries an IP67 waterproof rating, so it handles rain, snow, and temporary water exposure. It works well for outdoor 36V LED strip runs on building facades, pergolas, or other exposed locations.

Is the HLG-60H-36 a good option for powering 36V LED modules in a small illuminated sign?

Yes, provided the sign draws no more than 60W total at 36V. The HLG-60H-36 operates in constant-current mode with a CC range of 21-36V, so it can handle LED modules that run anywhere in that voltage window. The IP67 rating suits exterior-mounted signage exposed to weather.

Can I use the HLG-60H-36 for 36V LED high-bay or low-bay lighting in a warehouse?

Yes. At 60W it can drive a single 36V LED fixture or small cluster within its power budget. The -40 to +80 degree Celsius operating range covers typical warehouse temperatures, and the IP67 rating protects against dust and moisture in industrial environments.

How many meters of 36V LED strip can the HLG-60H-36 power?

Divide 60W by your strip's rated power per meter. A 36V strip drawing 10W/m allows up to 6 meters (60W / 10W per meter = 6m). A denser strip at 20W/m allows 3 meters. Always verify your strip's actual rated power per meter and stay at or below the 60W maximum.

Is the HLG-60H-36 suitable for installation in a coastal environment with salt spray?

Its IP67 rating protects against water immersion and dust, and the aluminium casing resists general corrosion. However, prolonged direct salt spray exposure can degrade any metal housing over time. Mounting inside a ventilated weatherproof enclosure is recommended for coastal installations to extend service life.

What are the differences between the HLG-60H-36, 36A, 36AB, and 36B models?

All four share the same 60W / 36V / 1.7A core specs with a CC range of 21-36V. The base HLG-60H-36 has fixed output and IP67 waterproofing. The -36A adds output voltage/current adjustment via potentiometer (IP65). The -36AB adds both adjustment and 1-10V/PWM dimming (IP65). The -36B provides dimming only and retains IP67.
