Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features
Constant voltage PWM style output with frequency 1KHz |
Plastic housing with class II design |
Built-in active PFC function |
No load power consumption<0.5W(Blank-Type) |
Function options: 2 in 1 dimming(dim-to-off); Auxiliary DC output |
3 years warranty |
General Specification
AC input voltage range | 90~295VAC |
AC inrush current (Typ.) | COLD START 30A(twidth=150μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 |
Short circuit protection | Shut down O/P voltage, re-power on to recovery |
Over current protection | 105~115% |
Setup time | 500ms / 230VAC 1200ms/115VAC |
Withstand voltage | I/P-O/P: 3.75kVAC |
Working temperature | Tcase=-20 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section) |
Safety standards | UL8750,CSA C22.2 NO.250.13-12; BS EN/EN 61347-1 & BS EN/EN 61347-2-13 independent, BS EN/EN62384,BIS IS15885(for IDLV-45-12,24,48 only), EAC TP TC 004 approved |
EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EAC TP TC 020 |
Dimension (LxWxH)(mm) | 120*75*25mm |
Packing | 0.22Kg;54pcs/13Kg/ 0.93CUFT |
Specifications
Specifications
-
BrandMean Well
-
SeriesIDLV Series
-
Power Rating45.12 Watt
-
Output Voltage48 Volt
-
Rated Current0.94 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetCB,CCC,CE,EAC,ENEC,RCM,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.72 in
-
Width2.95 in
-
Height0.98 in
-
Weight0.49 lb
