Mean Well MDS01N-15N SIP Package DC-DC Converter- 1W - 15V Out
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well MDS01N-15N SIP Package DC-DC Converter- 1W - 15V Out
Description
Description
Features:
- SIP7 package with international standard pinout
- Operating temperature range -40 ~ +95°C
- Comply with IEC/UL62368-1 (Expect for 15Vo/±15Vo) and LVD IEC60601-1
- Medical safety approved (1xMOPP/2xMOOP) according to IEC60601-1
- Low patient leakage current <2μA
- Protections: Short circuit (Continuous)
- 6KVDC hight I/O isolation (Reinforced insulation)
- Low cost
- 3 years warranty
General Specification
Input Voltage (Vdc)
5V (4.5 ~ 5.5V) | 12V (10.8 ~ 13.2V) | 24 (21.6 ~ 26.4V)
Output Voltage (Vdc)
1 Vo: 3.3V / 5V / 12V / 15V
2 Vo: ±5V / ±12V / ±15V
Overload Protection
Shut down the output when rated power≥102%, auto recovers
Operating Temperature
-40 ~ + 95°C
Short Circuit Protection
Continuous protection for a long time
Safety Certificate
CB / UL / EAC / CE / UKCA (62368-1 + 60601-1)
Dimension (LxWxH)
19.7 x 7.1 x 11.5 mm
Specifications
Specifications
-
BrandMean Well
-
SeriesMDS Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.00 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~95°C
-
Warranty3 Year
-
Length0.78 in
-
Width0.28 in
-
Height0.45 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well MDS01N-15N designed for?
The MDS01N-15N is a compact 1W DC-DC converter module intended for low-power embedded and OEM applications that need a regulated 15V output. Its SIP7 package and small 19.7 x 7.1 x 11.5 mm footprint make it suitable for space-constrained electronics.
What output does this model provide?
This model provides a single 15V DC output and has a 1W power rating. It is part of Mean Well's MDS01N SIP-package converter range and is positioned for low-power conversion needs where a compact isolated module is required.
Is the MDS01N-15N suitable for medical or safety-sensitive equipment?
The series is described as medically safety approved to IEC60601-1 with 1xMOPP and 2xMOOP, and it also features very low patient leakage current below 2 microamps. Buyers evaluating regulated medical equipment should still confirm the exact certification fit for their end product and compliance pathway.
How much isolation does the MDS01N-15N provide?
The converter is specified with 6KVDC input-to-output isolation and reinforced insulation. That makes it a stronger fit for designs where electrical separation and low leakage are important selection criteria.
Can this DC-DC converter operate in harsh temperature conditions?
Yes. The MDS01N-15N is rated for operation from -40°C to +95°C, which supports use in demanding industrial and enclosed equipment environments within its overall design limits.
What protection features are included on the MDS01N-15N?
This model includes continuous short-circuit protection, and the general specification also states overload shutdown at 102% or more of rated power with automatic recovery. These protections help support product durability in low-power electronic systems.
