Description
Description
Features
True sine wave output (THD<3%) |
High surge power up to 6400W |
Temperature-controlled cooling fan |
AC output voltage and frequency selectable by DIP S.W |
No load dissipation < 1.7W at standby saving mode |
-25℃~+70℃ wide operating temperature |
Power ON-OFF remote control |
Front panel indicator for operation status |
Protections: Short circuit / Overload / Over voltage |
Battery over-discharge protection(Low voltage disconnect) |
Suitable for lead-acid or li-ion batteries |
Remote controller (IRC1, IRC2, IRC3 accessory sold separately |
Support RS-232 communication(Communication cable order No.: DS-RJ11-RS232, sold separately |
Carry handle accessory available(Order NO.: DS-Carry handle, sold separately |
Conformal coating |
3 years warranty |
General Specification
AC output voltage range | 100/110/115/120VAC;200/220/230/240VAC selectable by DIP S.W |
AC output waveform | True sine wave, THD<3.0% |
Overload temperature | Protection type: Shut down o/p voltage, re-power on to recover |
Overload | 105~115% load for 180s, 115~150% load for 10s |
Withstand voltage | DC I/P - AC O/P:3.0KVAC AC O/P - FG:1.5KVAC |
Working temperature | -25~+70°C (refer to output derating curve ) |
Safety standards | CB IEC62368-1,Dekra Seal BS EN/EN62368-1,UL458, E13,EAC TP TC 004,AS/NZS 62368.1 approved |
EMC standards | EN55032 class A, BS En/EN61000-4-2,3,8 |
Dimension (LxWxH) | 420x270x98mm |
Packing | 1pcs / 10.4Kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesMeanWell NTS Series
-
Power Rating3200 Watt
-
Output Voltage110 Volt
-
Input Voltage20V~33V
-
No of Output1
-
Standards MetCB,CE,cUL,E13,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length16.54 in
-
Width10.63 in
-
Height3.86 in
-
Weight18.96 lb
