Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

×
High Resolution Image

Mean Well OWA-200E-48 Power Supply Moistureproof 200W 48V

$64.73 USD
Shipping calculated at checkout.

|

Your order will be processed within 24 hours

Description

Features

Input range 180~264VAC
Class II power unit, no FG
Built-in active PFC function
High efficiency up to 94%
No load power consumption <0.15W
Energy efficiency Level VI
Comply with EU ErP and CoC Version 5
Compliance to IEC/EN 61558-1,-2-16 and IEC/EN 60335-1 (except for OWA-200E-48,54) for household appliance
Fanless design, cooling by free air convection
Protections: Short circuit / Overload / Over voltage / Over temperature
Various DC plug quick adapter accessories are available
5 years warranty

General Specification

AC input voltage range 180~264VAC; 254~370VDC
AC inrush current COLD START 65A(twidth=550μs measured at 50% Ipeak) at 230VAC
Leakage current <0.25mA/240VAC
Over-voltage protection 116%~133% rated output voltage
Setup, rise, hold up time 500ms, 80ms, 10ms at full load
Withstand voltage I/P-O/P:4.2KVAC
Working temperature -35~+70°C
Safety standards DEKRA EN61558-1,-2-16; DEKRA EN60335-1(except for OWA-200E-48,54); EAC TP TC 004, IP67 (for power body) approved
EMC standards EN55032 Class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Dimension (LxWxH) 195x68x39.5mm
Packing 9pcs/12.88Kg

Specifications

  • Brand
    Mean Well
  • Series
    Mean Well OWA Series
  • Power Rating
    200 Watt
  • Output Voltage
    48 Volt
  • Rated Current
    4.17 Ampere
  • Input Voltage
    180V~264V
  • No of Output
    1
  • Dimming Control
    Non Dimmable
  • Standards Met
    CB,CCC,CE,EAC,ENEC,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -30°C~85°C
  • Warranty
    5 Year
  • Length
    4.13 in
  • Width
    2.68 in
  • Height
    0.91 in
  • Weight
    0.37 lb
