Description
Description
Features
AC input range selected by switch |
Built-in passive PFC function compliance to EN61000-3-2 |
With AC ON-OFF switch |
3 poles AC inlet with fuse holder |
Protections: Short circuit / Overload / Over voltage / Over temperature |
Charger type can be selected (Optional) |
Charger for lead-acid batteries |
2 color LED loading indicator |
Open frame models available (Without safety approval) |
Low cost, High reliability |
2 years warranty |
General Specification
AC input voltage range | 88~132VAC / 176~264VAC(selectable by switch); 248~370VDC |
AC inrush current (max.) | Cold start, 50A at 230VAC |
Overload protection | 90%~110% Constant current limiting, auto-recovery |
Over voltage protection | 108%~127% hiccup mode,auto-recovery |
Setup, rise, hold up time | 1000ms,50ms,16ms at full load |
Withstand voltage | I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
Working temperature | -10~+45ºC(refer to output derating curve) |
Safety standards | UL60950-1,TUV EN60950-1,EN60335,EN60335-1,EN60335-2-29 approved |
EMC standards |
EN55022(CISPR22) Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024 |
Dimension (LxWxH) (mm) | Case Type:180x96x 49mm;PCB:144x90x 33mm |
Packing | 16pcs / 17.9kg(without PFC); 16pcs / 20.1kg(with PFC) |
Specifications
Specifications
-
BrandMean Well
-
SeriesPA Series
-
Power Rating99.36 Watt
-
Output Voltage13.8 Volt
-
Rated Current7.2 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~45°C
-
Warranty2 Year
-
Length7.09 in
-
Width3.78 in
-
Height1.93 in
-
Weight2.43 lb
