Description
Description
EN55022(CISPR22) Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024
Key Features
- ✓Charger for lead-acid batteries (flooded, Gel and AGM) and Li-ion batteries (lithium iron and lithium manganese)
- ✓2/3/8 stage charging
- ✓Built-in battery rescue function
- ✓Controlled by micriprocessor
- ✓Universal AC input / Full range
- ✓Built-in active PFC function PF>0.95
- ✓Protection: Short circuit / Reverse polarity / Over voltage / Over temperature
- ✓3-color LED loading indicator
- ✓Built-in remote ON-OFF control
- ✓2-Bank charger
- ✓Built-in temperature compensation function
- ✓Built-in fan speed control (depends on charging current)
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesPB Series
-
Power Rating1000 Watt
-
Output Voltage57.6 Volt
-
Rated Current17.4 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty3 Year
-
Length11.81 in
-
Width7.24 in
-
Height2.76 in
-
Weight7.72 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other PB-1000 Models
2 other models| Model | Power | Battery Type | Battery Voltage | Charging Current | Price | |
|---|---|---|---|---|---|---|
| Mean Well PB-1000-24 Battery Chargers 1000W 28.8V 34.7A - 2/3/8 Stage W/PFC | 1000 Watt | Lead Acid Battery | 24V | — | $331.21 | View |
| Mean Well PB-1000-12 Battery Chargers 1000W 14.4V 60A - 2/3/8 Stage W/PFC | 1000 Watt | Lead Acid Battery | 12V | — | $331.63 | View |
