Mean Well RPD-65D Power Supply 65W 5V 24V 2.25A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RPD-65D Power Supply 65W 5V 24V 2.25A
Overview
RPD-65D is the CH1: 24V / CH2: 5V output model of this series: rated current CH1: 2.25A / CH2: 1.2A, rated power 60W, typical efficiency 81%.
Features
- Universal AC input/Full range
- 12V or 24V high peak output current capability
- Low leakage current<1mA
- Protections: Short circuit / Overload / Over voltage
- 60W free air convection, 77.1W with 18CFM forced air
- 100% full load burn-in test
- Fixed switching frequency at 65KHz
- 2 years warranty
Specifications
OUTPUT
- OUTPUT NUMBER
- CH1 / CH2
- DC VOLTAGE
- CH1: 24V / CH2: 5V
- RATED CURRENT
- CH1: 2.25A / CH2: 1.2A
- CURRENT RANGE
- CH1: 0 ~ 2.9A / CH2: 0 ~ 1.5A
- PEAK LOADNote.4
- CH1: 3.75A / CH2: Rated load
- RATED POWER
- 60W
- OUTPUT POWER (max.)
- Rated output power for convection; 77.1W with 18CFM min. forced air
- RIPPLE & NOISE (max.)Note.2
- CH1: 150mVp-p / CH2: 50mVp-p
- VOLTAGE ADJ. RANGE
- CH1:22.8 ~ 26.4V
- VOLTAGE TOLERANCENote.3
- CH1: ±2.0% / CH2: ±5.0%
- LINE REGULATION
- CH1: ±1.0% / CH2: ±1.0%
- LOAD REGULATION
- CH1: ±2.0% / CH2: ±5.0%
- SETUP, RISE TIME
- 800ms, 20ms at full load
- HOLD UP TIME (Typ.)
- 20ms at full load
INPUT
- VOLTAGE RANGE
- 90 ~ 264VAC 127 ~370VDC
- FREQUENCY RANGE
- 47 ~ 440Hz
- EFFICIENCY (Typ.)
- 81%
- AC CURRENT (Typ.)
- 1.5A/115VAC 0.9A/230VAC
- INRUSH CURRENT (Typ.)
- COLD START 25A/115VAC 50A/230VAC
- LEAKAGE CURRENT
- <1mA
PROTECTION
- OVERLOAD
- 90 ~ 125W output power Protection type : Hiccup mode, recovers automatically after fault condition is removed.
- OVER VOLTAGE
- CH1:27.6 ~ 32.4V Protection type : Hiccup mode, recovers automatically after fault condition is removed.
ENVIRONMENT
- WORKING TEMP.
- -20 ~ +60℃ (Refer to "Derating Curve")
- WORKING HUMIDITY
- 20 ~ 90% RH non-condensing
- STORAGE TEMP., HUMIDITY
- -40 ~ +85℃, 10 ~ 95% RH
- TEMP. COEFFICIENT
- ±0.04%/℃ (0 ~ 50℃) on CH1 output
- VIBRATION
- 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY & EMC
- SAFETY STANDARDS
- UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
- WITHSTAND VOLTAGE
- I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
- ISOLATION RESISTANCE
- I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
- EMC EMISSION
- Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
- EMC IMMUNITY
- Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, light industry level, EAC TP TC 020
OTHERS
- MTBF
- 2701.1K hrs min. Telcordia SR-332 (Bellcore) ; 523.4K hrs min. MIL-HDBK-217F (25℃)
- DIMENSION
- 127*76*29mm (L*W*H)
- PACKING
- 0.24Kg; 63pcs/16Kg/1.28CUFT
Test conditions and notes6
- 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
- 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
- 3. Tolerance : includes set up tolerance, line regulation and load regulation.
- 4. 10% duty cycle maximum within every second. Average output power should not exceed the rated power, output voltage above 90% DC voltage.
- 5. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
- 6. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
Technical drawings
Downloads
Certificates9
Test reports1
Catalogues1
FAQ
Can I use the RPD-65D in a medical monitor or diagnostic device?
This model is not medical safety approved; it complies with UL62368-1 and EN62368-1 (IT/AV equipment standards). While it features low leakage current (<1mA), it is designed for industrial and IT applications rather than medical devices. Its dual-output design includes 5V and 24V, with a 60W rating and 24V output current of 2.25A.
Is the RPD-65D a good fit for an industrial control panel that needs both logic and field power?
It can fit compact industrial or automation enclosures that need dual outputs, since this unit provides 5V and 24V in a 127.0 × 76.0 × 29.0 mm package. The 24V side is rated at 2.25A, so it is better suited to lower-power control electronics than heavier 24V loads.
Can I use the RPD-65D for embedded systems with a 5V control board and 24V peripherals?
Yes, this model is aimed at dual-rail designs because it combines 5V and 24V outputs in one constant-voltage power supply. With 60W total power and a compact 0.24 kg form factor, it fits embedded assemblies where space matters.
Is the RPD-65D suitable for outdoor or harsh-environment use?
No IP rating is listed for this model, so it should be treated as a power supply for protected indoor equipment rather than exposed outdoor use. Its operating temperature range is -20°C to +60°C, which supports a broad indoor equipment environment if the enclosure stays within that range.
How does the RPD-65D compare with other RPD dual-output models?
Within the listed siblings, RPD-65C is 60W at 12V 4.5A and 5V 1.2A. The RPD-65D is 60W at 24V 2.25A and 5V 1.2A. Other models like RPD-60A, RPD-60B, RPD-75A, and RPD-75B are not part of the RPD-65 series specification provided here.
