Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well RS-75-12 Power Supply 75W 12V
The RS-75 is a 75W Mean Well DIN rail power converter with a 29mm profile (input range: 125~373VDC, operating temperature: -25~+70°C).
Key Features
- ✓ 29mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection — no minimum load required
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating72 Watt
-
Output Voltage12 Volt
-
Rated Current6 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length5.08 in
-
Width3.86 in
-
Height1.5 in
-
Weight0.9 lb
::specification::
Frequently Asked Questions
Can I use the RS-75-12 for a 12V automation device or industrial control accessory?
Yes, this is a 12V constant-voltage power supply rated for 72W and 6A. It fits 12V automation or control loads that stay within those output limits.
Is the RS-75-12 suitable for a 12V CCTV, access control, or monitoring device?
It can be, provided the equipment needs 12V constant voltage and the total draw does not exceed 6A or 72W. Those ratings make it more suitable for medium 12V loads than smaller 12V adapters.
Would this model work for a 12V control panel with several low-voltage devices?
Yes, if all connected 12V devices together remain within 6A and 72W. Its open-frame size of 129.0 x 98.0 x 38.0 mm is also relevant when fitting it into a panel layout.
Can the RS-75-12 be used in machinery that sees vibration?
The product features specify 5G vibration resistance, which is useful in industrial equipment. The application still needs to match its 12V constant-voltage output and 6A maximum current.
Is the RS-75-12 meant for outdoor installations or wide temperature ranges?
Its operating temperature is rated from -25C to +70C, which supports demanding indoor temperature conditions. No IP rating is listed in the provided specs, so outdoor use should not be assumed.
