Mean Well RSDW20UW-05 Ultra-wide input DC/DC LED Driver 20W 5V - Heavy Duty
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RSDW20UW-05 Ultra-wide input DC/DC LED Driver 20W 5V - He...
The RSDW20UW is a 20W Mean Well power converter (input range: 8.5~160Vdc).
Key Features
- ✓ Input voltage range: 8.5~160Vdc
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Railway standards: EN45545-2 (fire), EN50155 / IEC60571, IEC61373 (shock & vibration)
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSDW20UW Series
-
Power Rating20 Watt
-
Output Voltage5 Volt
-
Rated Current4 Ampere
-
Input Voltage8.5V~160V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~95°C
-
Warranty3 Year
-
Length2 in
-
Width1 in
-
Height0.4 in
-
Weight0.06 lb
::specification::
Frequently Asked Questions
Can I use the RSDW20UW-05 for 5V industrial electronics where the input source varies widely?
Yes. This model provides a constant 5V output up to 4A and 20W, and its specified input range is 8-160VAC, which is wider than the standard RSDW20H models. That makes it suitable for 5V electronics operating from sources that fall anywhere within that stated range.
Is the RSDW20UW-05 appropriate for 5V embedded systems in heavy-duty or railway-related equipment?
It can be used for 5V embedded loads that require up to 4A and 20W. The provided features include EN50155 and EN45545 railway compliance, 4000VDC isolation, and an operating temperature range of -40°C to +95°C.
Can this converter support 5V display, logging, or communication modules in mobile equipment?
It is a fit for 5V display, logging, or communication modules if the total load remains at or below 4A and 20W. The 8-160VAC input range can be useful in equipment where the available input varies across a broad specified range.
Is the RSDW20UW-05 suitable for outdoor or high-temperature environments?
The operating temperature range is -40°C to +95°C, so it supports a wider temperature span than the RSDW20H series. No IP rating is listed in the specs, so outdoor exposure still requires a protective enclosure.
How does the RSDW20UW-05 compare with the other ultra-wide input versions?
The RSDW20UW-05, -12, and -15 all share 20W power, 8-160VAC input, 50.8 × 25.4 × 10.2 mm dimensions, 0.0285 kg weight, and -40°C to +95°C operation. Their output ratings differ: the -05 is 5V at 4A, the -12 is 12V at 1.67A, and the -15 is 15V at 1.33A.
