Mean Well SFTN01M-12 DC-DC Converter - 1W - 10.8~13.2V in 12V out
The SFTN01M is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSFTN Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.08 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the SFTN01M-12 in a compact 12V industrial control or monitoring circuit?
It can fit low-power 12V control or monitoring sections that need a constant-voltage output. This model is rated for 1W with a 12V output and 0.08A output current, so it is best suited to very small auxiliary loads rather than larger control hardware.
Is the SFTN01M-12 suitable for embedded 12V electronics inside space-limited equipment?
Yes, its 15.24 x 10.9 x 7.1 mm size and 0.0012 kg weight make it appropriate where board or enclosure space is tight. The 12V constant-voltage output and 1W power rating mean it is intended for small embedded 12V sections, not higher-power subsystems.
Can this converter be used for a small 12V automation signal interface?
It may be appropriate for a small automation interface that needs a regulated 12V output and draws no more than 0.08A. Because the unit is only 1W, it is better matched to light-duty signal or interface tasks than to larger automation loads.
Is the SFTN01M-12 intended for outdoor or harsh-environment use?
The operating temperature range is -40°C to +90°C, so the temperature specification is broad. However, no IP rating is listed in the provided specs, so indoor or outdoor enclosure protection is not specified by this data.
How does the SFTN01M-12 compare with other SFTN01M models?
Within the SFTN01M series, the listed siblings are SFTN01M-05 at 1W, 5V, 200A; SFTN01M-09 at 1W, 9V, 111A; and SFTN01M-15 at 1W, 15V, 0.07A. The SFTN01M-12 version is the 1W, 12V model with 0.08A output current.
