Description
Description
Features
2" x 1" compact size |
2:1 wide input range |
1500VDC I/O isolation |
Built-in remote ON/OFF control |
Built-in EMI filter |
Protection: Short circuit / Overload / Input and output over voltage |
Cooling by free air convection |
Built-in remote sense |
100% full load burn-in test |
Low cost, high reliability |
Trimming output (±10%) |
High efficiency up to 93% |
Output 3.3V/9V models available |
2 years warranty |
General Specification
Voltage set point accuracy | ±2% (max.) |
Line regulation | ±0.5% (max.) |
Load regulation | ±0.5% (max.)@10~100% load |
Overload protection | 110%~180%, auto-recovery |
Efficiency | 92% |
Over voltage protection | Clamp by TVS diode |
I/O isolation voltage | 1500VDC (min.) |
I/O isolation resistance | 100MQ(min.) @500VDC |
Working temperature | -40~+80°C (refer to output derating curve) |
Storage temperature | -55°C to +105°C |
Case material | Six-sided shield metal case |
EMC | Compliance to EN55022 class A, EN61000-4-2,3,4,5,6,8, FCC part15 class A |
Dimension (LxWxH) (mm) | 2" x 2" x 0.43" |
Specifications
Specifications
-
BrandMean Well
-
SeriesSKA Series
-
Power Rating35 Watt
-
Output Voltage12 Volt
-
Rated Current3.33 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty2 Year
-
Length2 in
-
Width2 in
-
Height0.43 in
-
Weight0.13 lb
