Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SKM50B-12 DC-DC Converter - 50W - 18~36V in 12V out

Name: Mean Well SKM50B-12 DC-DC Converter - 50W - 18~36V in 12V out
Brand: Mean Well
SKU: SKM50B-12
Price: 45.47 USD
Availability: InStock

SKU:

SKM50B-12

$45.47 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

DIP 2"x 1" compact size

2:1 wide input range

High Efficiency up to 92%

1500KVDC I/O isolation

Remote ON/OFF control and Trimming the output

Comply with CE / FCC without external components

Protection: Short circuit / Overload / Input and output over-voltage

Cooling by free air convection

Six-sided shield metal case

100% burn-in test

Low cost / High reliability

Approvals: FCC / EAC / CE / UKCA

2 years warranty

General Specification

Voltage set point accuracy	±2.0% (max.)
Line regulation	±0.2% (max.)
Load regulation	0.5%
Overload protection	110%~140%, Protection type: Recovers automatically after fault condition is removed
Efficiency	91% ; 91% ; 92% \| 91% ; 90% ; 91%
Short circuit protection	All output equipped with short circuit \| Protection type: Hiccup mode, recovers automatically after fault condition is removed
I/O isolation voltage	1500VDC (min.)
I/O isolation resistance	I/P-O/P: 100M Ohms / 500VDC / 25 / 70% RH
Working temperature	-40~+75°C (refer to output derating curve)
EMC	Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B
Dimension (LxWxH) (mm)	50.8 x 25.4 x 13.7 mm \| 2" x 1" x 0.54" inch

Specifications

Brand

Mean Well
Series

SKM Series
Power Rating

50 Watt
Output Voltage

12 Volt
Rated Current

4.17 Ampere
Input Voltage

18V~36V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC,FCC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~75°C
Warranty

2 Year
Length

2 in
Width

1 in
Height

0.54 in
Weight

0.09 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Features

DIP 2"x 1" compact size

2:1 wide input range

High Efficiency up to 92%

1500KVDC I/O isolation

Remote ON/OFF control and Trimming the output

Comply with CE / FCC without external components

Protection: Short circuit / Overload / Input and output over-voltage

Cooling by free air convection

Six-sided shield metal case

100% burn-in test

Low cost / High reliability

Approvals: FCC / EAC / CE / UKCA

2 years warranty

General Specification

Voltage set point accuracy

±2.0% (max.)

Line regulation

±0.2% (max.)

Load regulation

0.5%

Overload protection

110%~140%, Protection type: Recovers automatically after fault condition is removed

Efficiency

91% ; 91% ; 92% | 91% ; 90% ; 91%

Short circuit protection

All output equipped with short circuit | Protection type: Hiccup mode, recovers automatically after fault condition is removed

I/O isolation voltage

1500VDC (min.)

I/O isolation resistance

I/P-O/P: 100M Ohms / 500VDC / 25 / 70% RH

Working temperature

-40~+75°C (refer to output derating curve)

EMC

Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B

Dimension (LxWxH) (mm)

50.8 x 25.4 x 13.7 mm | 2" x 1" x 0.54" inch
