Description
Description
Features
1500VDC I/O isolation |
Internal SMD technology |
Operating temperature range -40~85oC without derating |
Built-in EMI filter |
Protection: Short circuit |
Cooling by free air convection |
Non-conductive plastic case |
100% full load burn-in test |
Low cost, high reliability |
Dual in line package for SMA01 |
Industry standard pinout |
2 years warranty |
General Specification
Voltage set point accuracy | ±2% (max.) |
Line regulation | ±1.2% (max.) for 1% input variation |
Load regulation | ±8% (max.)@20~100% load |
Input reflected ripple | 100mVp-p |
Efficiency | 80% (typical) |
Short circuit protection | Momentary |
Switching frequency | 100kHz (min.) |
I/O isolation voltage | 1500VDC (min.) |
I/O isolation resistance | 100MQ(min.)@500DC |
Working temperature | -40°C to +85°C |
Storage temperature | -55°C to +125°C |
EMC | Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B |
Isolation capacitance | 80pF (max.) |
Dimension (LxWxH) (mm) | 0.46""x 0.24""x 0.4""; 0.5""x 0.4""x 0.28"" |
Safety standards | UL60950-1 approved |
Specifications
Specifications
-
BrandMean Well
-
SeriesSMA Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty2 Year
-
Length0.5 in
-
Width0.4 in
-
Height0.28 in
-
Weight0 lb
