Mean Well ADS-15524 Power Supply 154.2W 48V 2.9A - 5V Output
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ADS-15524 Power Supply 154.2W 48V 2.9A - 5V Output
The ADS is a 155W Mean Well. power converter. and an input range of 88~264VAC.
Key Features
- ✓ Input voltage range: 88~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesADS Series
-
Power Rating154.2 Watt
-
Output Voltage48 Volt
-
Rated Current2.9 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty2 Year
-
Length7.83 in
-
Width4.33 in
-
Height1.97 in
-
Weight2.2 lb
::specification::
Frequently Asked Questions
What is the ADS-15548 typically used for?
The Mean Well ADS-15548 is typically used in higher-voltage DC systems that need a 48V main output and an auxiliary 5V output. With 154.2W of rated power and 2.9A on the main 48V output, it is a good fit for applications that need a higher-voltage rail while still benefiting from a dual-output power supply design.
Can the ADS-15548 support 48V DC system loads?
Yes. The ADS-15548 provides a main 48V output rated at 2.9A, making it suitable for systems designed around that voltage class when the total demand stays within the unit's 154.2W main-output capacity. It is the 48V option in this ADS group rather than a lower-voltage 12V or 24V unit.
Is the ADS-15548 a good fit for systems that need a 48V rail plus a 5V auxiliary output?
Yes. The ADS-15548 is useful in designs where the main equipment needs 48V DC and supporting electronics benefit from a separate 5V output. That dual-output structure can make it more practical for mixed-voltage system layouts than a supply that only provides a single 48V rail.
Can the ADS-15548 be used where a higher-voltage output is needed instead of 12V or 24V?
Yes. The ADS-15548 is intended for applications built around a 48V DC requirement, so it is the better fit when the system is designed for that voltage class rather than 12V or 24V. The correct choice still depends on matching the product's output voltage and available current to the load.
Will the ADS-15548 operate from common AC mains ranges?
Yes. The product data lists an AC input range of 88-264VAC, so the ADS-15548 can operate from common 120V and 240V AC mains systems within that range. That helps simplify use across different facilities and regions.
Is the ADS-15548 suitable for exposed outdoor installation?
The current product data does not list a waterproof IP rating, so the ADS-15548 should be treated as an indoor or enclosure-mounted power supply rather than a directly exposed outdoor unit. Its working temperature is listed as -10°C to +60°C, but the final enclosure still needs to match the environment.
How does the ADS-15548 compare with the rest of the ADS family?
The ADS-15548 delivers 154.2W at 48V and 2.9A on the main output. In the same family, the ADS-15512 provides 153W at 12V and 11.5A, the ADS-15524 provides 154.2W at 24V and 5.8A, and the smaller ADS-5512 and ADS-5524 provide 51W and 58W for lower-power applications. The main difference is the output voltage class and the available current at that voltage.
