Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well HLG-240H-48AB Power Supply 240W 48V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HLG-240H-48AB Power Supply 240W 48V - Adjustable and Dimm...
The HLG-240H is a 240W Mean Well power converter (input range: 90~305VAC).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating240 Watt
-
Output Voltage48 Volt
-
Rated Current5 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty7 Year
-
Length9.61 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.87 lb
::specification::
Frequently Asked Questions
Can I use the HLG-240H-48AB to power 48V LED strip lighting in a commercial canopy or covered walkway?
Yes. The HLG-240H-48AB provides 240W at 48V and is IP65 water-resistant, which protects against dust and low-pressure water jets. It is well suited for covered outdoor areas such as canopies, walkways, and semi-enclosed signage enclosures where 48V LED strips are used. The built-in dimming input also lets you adjust brightness on-site.
Is the HLG-240H-48AB suitable for dimming 48V LED signage from a building management system?
Yes. The AB suffix indicates both adjustable output and a 1-10V/PWM dimming interface. You can pair with the HLG-240H-48AB to a BMS or lighting controller that outputs a 1-10V or PWM signal to dim the 48V LED signage remotely. The adjustable potentiometer also allows manual fine-tuning of voltage and current.
Can I power 48V LED high-bay fixtures with the HLG-240H-48AB in a warehouse?
Yes. At 240W and 48V with 5A output, the HLG-240H-48AB can drive 48V high-bay LED fixtures up to 240W total. The constant-current mode with a CC range of 24-48V accommodates LED modules with varying forward voltages. The dimming input allows integrating the driver into an occupancy-based lighting control scheme.
How many meters of 48V LED strip can the HLG-240H-48AB support?
That depends on the strip's rated power per meter. The HLG-240H-48AB supplies up to 240W at 48V. For example, if your 48V strip draws 14.4W per meter, you could run up to 240 / 14.4 = 16.6 meters. Always check your strip's rated power per meter and keep total wattage at or below 240W.
Can the HLG-240H-48AB be mounted in a damp location or semi-enclosed outdoor cabinet?
Yes. The IP65 rating protects against dust ingress and low-pressure water jets from any direction, making it suitable for damp locations, ventilated outdoor cabinets, and covered canopy installations. For direct rain exposure or standing water, consider the IP67-rated HLG-240H-48B instead.
What is the difference between the HLG-240H-48, 48A, 48AB, and 48B variants?
All four share 240W / 48V / 5A core specs. The base HLG-240H-48 has fixed output and IP67 waterproof rating. The -48A adds output voltage/current adjustment via potentiometer (IP65). The -48AB adds both adjustment and 1-10V/PWM dimming input (IP65). The -48B provides dimming input only and retains IP67 waterproof rating.
