Mean Well DKM10A-15 DC-DC Converter - 10W - 9~18V in ±15V out
SKM10 and DKM10 series are 10W isolated and regulated module type DC-DC converter with DIP 1"x1" package. It features international standard pins, a high efficiency up to 90%, wide working temperature range -40~+85℃, 1.5KVDC I/P-O/P isolation voltage, Compliance to EN55032 radiated Class A without additional components, continuous-mode short circuit protection, etc. The models account for different input voltage 4.7~9V, 9~18V, 18~36V and 36~75V 2:1 wide input range, and various output voltage, 3.3V/5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for all kinds of systems, such as industrial control, telecommunication field, distributed power architecture, and so on.
Key Features
- ✓✓✓DIP 1"x1" package with industry standard pinout
- ✓✓✓2:1 wide input range
- ✓✓✓Operating temperature range -40 ~ +85℃
- ✓✓✓No minimum load required
- ✓✓✓Comply to EN55032 radiated Class A without additional components
- ✓✓✓High efficiency up to 90%
- ✓✓✓Protections: Short circuit (Continuous} / Overload / Over voltage / Input under voltage
- ✓✓✓1.5KVDC I/O isolation
- ✓✓✓Remote ON/OFF control and Triming output (±10%)
- ✓✓✓3 years warranty
-
BrandMean Well
-
SeriesDKM Series
-
Power Rating10 Watt
-
Output Voltage15 Volt
-
Rated Current0.33 Ampere
-
Input Voltage9V~18V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can I use the DKM10A-15 for 15V analog or instrumentation circuits in embedded equipment?
Yes, it is appropriate for 15V constant-voltage loads when the source is within the 9-18V input range. The available output power is 10W, so it fits lighter analog and instrumentation loads rather than larger 15V systems.
Is the DKM10A-15 suitable for low-power industrial control electronics that run on 15V?
It can be used for low-power 15V control electronics fed from a 9-18V supply. The published limits are 10W total power and 333A listed output current.
Can this converter be used in compact embedded assemblies that need 15V output?
Yes, the 25.4 × 25.4 × 10.2 mm package is small enough for compact embedded hardware. It is meant for 15V constant-voltage applications where the source stays within 9-18V and the load remains within 10W.
How does the DKM10A-15 compare with the 5V and 12V versions?
These models share the same 10W platform and 9-18V input range, but they provide different outputs. The DKM10A-05 is 5V at 1A, the DKM10A-12 is 12V at 416A, and the DKM10A-15 is 15V at 333A.
Is the DKM10A-15 suitable for outdoor use or high-temperature equipment?
The converter is rated for -40°C to +85°C operation, which supports a wide equipment temperature range. No IP rating is listed in the provided data, so the stated specs do not support exposed outdoor installation.
