Mean Well DKM10E-12 DC-DC Converter - 10W - 4.7~9V in ±12V out
SKM10 and DKM10 series are 10W isolated and regulated module type DC-DC converter with DIP 1"x1" package. It features international standard pins, a high efficiency up to 90%, wide working temperature range -40~+85℃, 1.5KVDC I/P-O/P isolation voltage, Compliance to EN55032 radiated Class A without additional components, continuous-mode short circuit protection, etc. The models account for different input voltage 4.7~9V, 9~18V, 18~36V and 36~75V 2:1 wide input range, and various output voltage, 3.3V/5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for all kinds of systems, such as industrial control, telecommunication field, distributed power architecture, and so on.
Key Features
- ✓✓✓DIP 1"x1" package with industry standard pinout
- ✓✓✓2:1 wide input range
- ✓✓✓Operating temperature range -40 ~ +85℃
- ✓✓✓No minimum load required
- ✓✓✓Comply to EN55032 radiated Class A without additional components
- ✓✓✓High efficiency up to 90%
- ✓✓✓Protections: Short circuit (Continuous} / Overload / Over voltage / Input under voltage
- ✓✓✓1.5KVDC I/O isolation
- ✓✓✓Remote ON/OFF control and Triming output (±10%)
- ✓✓✓3 years warranty
-
BrandMean Well
-
SeriesDKM Series
-
Power Rating10 Watt
-
Output Voltage12 Volt
-
Rated Current0.41 Ampere
-
Input Voltage4.7V~9V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can I use the DKM10E-12 for a 12V embedded controller or industrial interface board?
It can be used where a constant 12V output is needed from a 4-9VAC input source. Application fit depends on staying within the product's 10W power rating and its listed 416A output current.
Is the DKM10E-12 suitable for low-power 12V automation electronics?
Yes, it is aimed at low-power constant-voltage 12V applications rather than higher-power loads. Its main operating limits are 10W total power and a 4-9VAC input range.
Would the DKM10E-12 work in compact industrial electronics where board space is limited?
This model is physically compact at 25.4 × 25.4 × 10.2 mm, so it can suit dense embedded or industrial assemblies. It provides constant 12V output and is intended for applications that fit within its 10W rating.
Can the DKM10E-12 be used in equipment exposed to wide temperature swings?
The specified operating range is -40°C to +85°C, so the temperature spec supports use in demanding thermal conditions. The product does not list an IP rating, so the specs do not establish outdoor or washdown suitability.
What is the difference between the DKM10E-12 and the other DKM10E versions?
The listed DKM10E siblings all share 10W power, 25.4 × 25.4 × 10.2 mm dimensions, 0.018 kg weight, CE certification, a 3-year warranty, and a -40°C to +85°C operating range. The DKM10E-12 is the 12V version with listed 416A output current, while the DKM10E-05 is 5V at 1A and the DKM10E-15 is 15V at 333A.
