Mean Well DPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in ±15V out
The DPUN02M is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDPUN Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~105°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the DPUN02M-15 in a 12V automation system that needs low-power ±15V rails?
Yes, if the source is within 10-13VAC and the load requires a constant-voltage ±15V output. Its 2W rating and 0.07A output current suit small control, analog, or interface sections rather than heavier industrial loads.
Is the DPUN02M-15 appropriate for embedded test, measurement, or analog signal circuits?
It is appropriate for low-power embedded circuits that need ±15V from a 10-13VAC input source. The available output is limited to 2W and 0.07A, so it fits light analog stages better than broad system power distribution.
Can this model be used for compact board-level control electronics that need bipolar 15V?
Yes, its 19.6 × 10.2 × 7.2 mm footprint supports compact board-level designs that need constant-voltage ±15V output. The electrical limit is still 2W with 0.07A output current, so it should be reserved for low-power control or signal circuitry.
What is the difference between the DPUN02M-15 and the other DPUN02M versions?
The DPUN02M-05, DPUN02M-12, and DPUN02M-15 all share 2W power, 19.6 × 10.2 × 7.2 mm size, 0.0027 kg weight, and a -40°C to +105°C operating range. Their outputs differ: 5V at 200A for the DPUN02M-05, 12V at 0.08A for the DPUN02M-12, and 15V at 0.07A for the DPUN02M-15.
Can the DPUN02M-15 be used in outdoor or harsh-temperature environments?
Its specified operating range is -40°C to +105°C, so temperature capability is broad. However, no IP rating is listed, so outdoor exposure or washdown use is not defined by the published specs and depends on the enclosure around the converter.
