Mean Well DPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in ±15V out
Description
Description
The DPUN02L is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDPUN Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~105°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the DPUN02L-15 for low-power +/-15V rails in embedded measurement hardware?
Yes, if the measurement section stays within the converter's 2W rating. This model provides a ±15V constant-voltage output from a 4.5~5.5V input range. That makes it suitable for compact embedded circuits that need low-power ±15V rails.
Is the DPUN02L-15 appropriate for industrial signal-conditioning modules?
It can fit low-power signal-conditioning or interface modules that require ±15V output. The published output current is 0.07A, and the converter is rated for 2W. Its 19.6 × 10.2 × 7.2 mm dimensions also support space-constrained industrial boards.
Can this model convert a 5V-class input into +/-15V for automation electronics?
Yes. The listed input range is 4.5~5.5V, and the output is ±15V in constant-voltage mode. That makes it a fit for low-power automation or control electronics that start from a low-voltage input and need higher bipolar rails.
Is the DPUN02L-15 rated for outdoor or high-temperature equipment?
The provided operating temperature range is -40°C to +105°C, which supports use across a wide temperature span. No IP rating is listed in the supplied specs. Because of that, temperature capability is stated, but outdoor or water-exposed suitability is not established on this page.
What are the key differences between the DPUN02L-15 and the other DPUN02L models?
The DPUN02L-05, DPUN02L-12, and DPUN02L-15 are all listed as 2W converters in the same series. Their outputs are 5V, 12V, and 15V respectively, with listed currents of 200A, 0.08A, and 0.07A. This unit is the highest-output-voltage version among those three siblings.
Other DPUN02 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well DPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in ±15V out | 2W | 15V | 0.06A | Indoor | $4.67 | View |
| Mean Well DPUN02N-12 DC-DC Converter - 2W - 21.6~26.4V in ±12V out | 2W | 12V | 0.08A | Indoor | $4.67 | View |
| Mean Well DPUN02N-05 DC-DC Converter - 2W - 21.6~26.4V in ±5V out | 2W | 5V | 0.2A | Indoor | $4.67 | View |
| Mean Well DPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in ±15V out | 2W | 15V | 0.06A | Indoor | $4.67 | View |
| Mean Well DPUN02M-12 DC-DC Converter - 2W - 10.8~13.2V in ±12V out | 2W | 12V | 0.08A | Indoor | $4.67 | View |
| Mean Well DPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in ±5V out | 2W | 5V | 0.2A | Indoor | $4.67 | View |
| Mean Well DPUN02L-12 DC-DC Converter - 2W - 4.5~5.5V in ±12V out | 2W | 12V | 0.08A | Indoor | $4.73 | View |
| Mean Well DPUN02L-05 DC-DC Converter - 2W - 4.5~5.5V in ±5V out | 2W | 5V | 0.2A | Indoor | $4.67 | View |
