Mean Well GC30E-4P1J Portable Chargers 30W 14.3V 2.09A - Green Adaptor
The GC30E is a 30W Mean Well power converter (input range: 3.6~4.4V).
Key Features
- ✓ Input voltage range: 3.6~4.4V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: EN60950-1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGC Series
-
Power Rating30 Watt
-
Output Voltage14.3 Volt
-
Rated Current2.09 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~50°C
-
Warranty2 Year
-
Length4.25 in
-
Width2.64 in
-
Height1.42 in
-
Weight0.89 lb
::specification::
Frequently Asked Questions
What is the Mean Well GC30E-4P1J designed for?
The GC30E-4P1J is a 30W portable charger intended for lead-acid batteries, including flooded, gel, and AGM types, as well as certain lithium-ion battery chemistries noted by the manufacturer. It provides a 14.3V output at up to 2.09A. This makes it suitable for battery charging applications that match those output requirements.
What are the key electrical ratings of the GC30E-4P1J?
This model is rated for 30W output with a nominal output of 14.3V DC and 2.09A. It accepts a universal AC input range of 90 to 264VAC, and also supports 127 to 370VDC input. The charger operates in constant current and constant voltage modes.
Is the GC30E-4P1J suitable for portable or field use?
Yes, this model is built in a fully enclosed plastic case and is described as a portable charger. Its compact dimensions of 108 x 67 x 36 mm and approximate weight of 405g make it easier to handle and transport than larger industrial chargers. It also includes a Euro type 6-foot 2-pin power cord.
What operating environment is the GC30E-4P1J rated for?
The specified working temperature range is 0°C to 50°C, with derating referenced by the manufacturer. This makes it appropriate for indoor and similar controlled-use environments within that temperature window. Buyers should confirm their application stays within the stated thermal limits.
What protections are included in the GC30E-4P1J?
The GC30E-4P1J includes protection for short circuit, overload, over-voltage, and over-temperature conditions. Its over-voltage protection is specified at 110% to 135%, with shutdown and latch-off behavior until power is reapplied. These features help protect both the charger and the connected load during abnormal conditions.
How can I tell the charging status on this model?
This charger includes a 2-color LED indicator for charging status. That provides a quick visual status reference without needing external monitoring equipment. For buyers comparing portable chargers, this is a useful built-in status feature.
What approvals and warranty come with the GC30E-4P1J?
The product description lists approvals including TUV, UL, CUL, CB, FCC, and CE, and the general specification also references UL62368-1, CSA22.2, and EAC TP TC 004 approval. EMC compliance includes standards such as EN55022 Class B and FCC Part 15 Class B. The listed warranty period for this model is 2 years.
