Mean Well GC30U-11P1J Portable Chargers 21.6W 7.2V 3A - Green Adaptor
The GC30U is a 30W Mean Well power converter (input range: 3.6~4.4V).
Key Features
- ✓ Input voltage range: 3.6~4.4V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGC Series
-
Power Rating21.6 Watt
-
Output Voltage7.2 Volt
-
Rated Current3 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~50°C
-
Warranty2 Year
-
Length4.25 in
-
Width2.64 in
-
Height1.42 in
-
Weight0.89 lb
::specification::
Frequently Asked Questions
What type of batteries is the Mean Well GC30U-11P1J designed to charge?
The GC30U-11P1J is designed for lead-acid batteries, including flooded, gel, and AGM types, as well as lithium-ion chemistries listed in the product description. It is a portable charger model rated for 7.2V output and 3A charging current. This makes it suitable for buyers looking for a compact charger for supported 7.2V battery applications.
What are the key output specifications of the GC30U-11P1J?
This model is rated at 21.6W with a 7.2V output and 3A rated current. It operates in constant current and constant voltage modes for charging use. Those specs make it a fit for applications that require a compact 7.2V portable charger from the Mean Well GC series.
Is the GC30U-11P1J suitable for portable or field-use applications?
Yes, this model is built as a portable charger in a fully enclosed plastic case and includes a USA type 6FT 2-pin power cord. Its compact size of 108 x 67 x 36 mm and weight of about 405g help support portable use. Buyers looking for a lightweight bench or mobile charging solution often prefer this form factor.
What input range and power characteristics does this charger support?
The GC30U-11P1J accepts a universal AC input range of 90 to 264VAC, or 127 to 370VDC. It also has no-load power consumption below 1.0W and is specified for continued load use. These characteristics make it practical for buyers needing broad input compatibility across different AC environments.
What protections and status indicators are included on the GC30U-11P1J?
This charger includes protection for short circuit, overload, over voltage, and over temperature. It also has a 2-color LED indicator for charging status. These features help commercial buyers evaluate the unit for reliability and basic charge-state visibility.
What operating environment is the GC30U-11P1J rated for?
The specified working temperature range is 0°C to 50°C, with reference to the derating curve noted in the product data. The unit is intended for use within that ambient temperature range rather than extreme hot or freezing conditions. Buyers should use that range when screening chargers for indoor or light industrial environments.
Does the Mean Well GC30U-11P1J include certifications and warranty coverage?
Yes, the product description lists approvals including TUV, UL, CUL, CB, FCC, and CE, and the general specification also references UL62368-1, CSA22.2, and EAC TP TC 004 approval. The charger includes a 2-year warranty. This combination is useful for buyers who need a branded charger with recognized compliance coverage.
