Mean Well HDR-100-15N Ultra Slim Step Shape Power Supply 100W 15V - DIN Rail
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HDR-100-15N Ultra Slim Step Shape Power Supply 100W 15V -...
The HDR-100 is a 100W Mean Well power converter (input range: 85~2 VAC).
Key Features
- ✓ Input voltage range: 85~2 VAC
- ✓ DC output voltage adjustable ±10%
- ✓ Cooling by free air convection
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHDR Series
-
Power Rating97.5 Watt
-
Output Voltage15 Volt
-
Rated Current6.5 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetBSMI,CB,CE,cUL,EAC,RCM,TUV,UL
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length3.54 in
-
Width2.76 in
-
Height2.15 in
-
Weight0.6 lb
::specification::
Frequently Asked Questions
What control panel loads is the HDR-100-15N sized for?
At 97.5W and 6.5A on a 15V bus, the HDR-100-15N suits applications such as industrial relay modules, field bus power supplies, and 15V sensor networks in control panels. Its DIN rail-mount step-shape body makes it easy to slot into standard enclosures alongside other rail components.
How does the HDR-100-15N differ from the HDR-100-15?
The HDR-100-15N is rated at 97.5W / 6.5A compared to the HDR-100-15 at 92W / 6.13A. Both are physically identical at 90.0 × 70.0 × 54.5 mm, weigh 0.27 kg, carry the same full certification set, and come with a 3-year warranty.
Does the HDR-100-15N support universal input voltage?
Yes, the HDR-100-15N accepts 85–264VAC input, covering the full range of worldwide mains voltages. No voltage selector switch is required when deploying across different regions.
Is the output voltage field-adjustable on the HDR-100-15N?
Yes, the DC output voltage on the HDR-100-15N is adjustable. The no-load power consumption remains below 0.3W, which is useful in continuously energized panels where standby efficiency matters.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other HDR-100 Models
7 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well HDR-100-12 Ultra Slim Step Shape Power Supply 100W 12V - DIN Rail | 82.5W | 12V | 7.1A | Indoor | $29.71 | View |
| Mean Well HDR-100-48 Ultra Slim Step Shape Power Supply 100W 48V - DIN Rail | 92.2W | 48V | 1.92A | Indoor | $29.65 | View |
| Mean Well HDR-100-24 Ultra Slim Step Shape Power Supply 100W 24V - DIN Rail | 92W | 24V | 3.83A | Indoor | $26.49 | View |
| Mean Well HDR-100-15 Ultra Slim Step Shape Power Supply 100W 15V - DIN Rail | 92W | 15V | 6.13A | Indoor | $27.85 | View |
| Mean Well HDR-100-48N Ultra Slim Step Shape Power Supply 100W 48V - DIN Rail | 100.8W | 48V | 2.1A | Indoor | $29.65 | View |
| Mean Well HDR-100-24N Ultra Slim Step Shape Power Supply 100W 24V - DIN Rail | 100.8W | 24V | 4.2A | Indoor | $34.45 | View |
| Mean Well HDR-100-12N Ultra Slim Step Shape Power Supply 100W 12V - DIN Rail | 90W | 12V | 7.5A | Indoor | $29.27 | View |
