Mean Well HRPG-1000-48 Power Supply 1008W 48V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HRPG-1000-48 Power Supply 1008W 48V
HRPG-1000 is a single output enclosed type AC/DC power supply providing 1000 W output power for a wide range of industrial applications. This series operates for 90-264 VAC input voltage and offers models with different rated voltage ranging between 12 and 48 V that can satisfy the demands for all kinds of industrial equipments. Each model is cooled by the built-in fan with speed control, working for the temperature up to 70°C. Moreover, HRPG-1000 has various built-in functions such as auxiliary power, remote sense and remote on-off control, offering vast design flexibility for industrial application.
Key Features
- ✓Universal AC input / Full range
- ✓Built-in active PFC function
- ✓PF>0.95
- ✓High efficiency up to 94%
- ✓Withstand 300VAC surge input for 5 seconds
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Built-in cooling fan ON-OFF control • Current sharing up to 4000W (3+1)
- ✓Built-in DC OK signal
- ✓Built-in remote ON-OFF control
- ✓Standby 5V@0.3A
- ✓Built-in remote sense function
- ✓No load power consumption<0.75W (Note.6)
- ✓5 years warranty
-
BrandMean Well
-
SeriesHRPG Series
-
Power Rating1008 Watt
-
Output Voltage48 Volt
-
Rated Current21 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~70°C
-
Warranty5 Year
-
Length8.58 in
-
Width4.13 in
-
Height2.5 in
-
Weight3.37 lb
::specification::
Frequently Asked Questions
Can I use the HRPG-1000-48 for a 48V industrial or telecom-style DC load?
Yes, this model is a constant-voltage 48V supply rated for 1008W and up to 21A. That makes it suitable for larger 48V equipment loads where a lower-voltage model such as 12V, 15V, or 24V would not match the required system voltage.
Is the HRPG-1000-48 suitable for a 48V automation or control platform with multiple powered devices?
It can be a fit when the overall 48V load stays within 21A and 1008W. The wide 90-264VAC input range and 1U low-profile housing support use in equipment that needs a high-power 48V source in a relatively compact 218.0 x 105.0 x 63.5 mm package.
Can this supply support 48V embedded systems or industrial electronics that need constant-voltage output?
Yes, it is intended for constant-voltage 48V applications rather than constant-current use. With 21A available, it provides more 48V capacity than smaller HRPG-150-48, HRPG-200-48, HRPG-300-48, HRPG-450-48, or HRPG-600-48 models.
How does the HRPG-1000-48 compare with related high-power HRPG options?
In the HRPG-1000 range, HRPG-1000-12 is 960W at 12V and 80A, HRPG-1000-15 is 960W at 15V and 64A, HRPG-1000-24 is 1008W at 24V and 42A, and this HRPG-1000-48 is 1008W at 48V and 21A. The HRPG-1000N3 family is listed at 1000W with 12V/80A, 24V/42A, 28V/28A, and 21V/21A for the -12, -24, -36, and -48 versions.
Is the HRPG-1000-48 rated for outdoor service or temperature extremes?
The operating temperature range is -40C to +70C, so the unit is specified for a broad temperature range. However, no IP rating is shown in the provided specs, so the data does not confirm outdoor exposure or protection against water and dust.
