Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well MPQ-200B Power Supply 200W 5V 12V -5V -12V
<150 μA/264VAC
Key Features
- ✓Universal AC input/Full range
- ✓Low leakage current < 150μA
- ✓Protections: Short circuit/Overload/Over voltage/Over temperature
- ✓Free air convection for 140W and forced air convection for 200W
- ✓Medical safety approved(2 x MOPP between primary to secondary)
- ✓With power good and fail signal output
- ✓Built-in remote ON-OFF control
- ✓Built-in remote sense function
- ✓Fixed switching frequency at 100KHz
- ✓3 years warranty
-
BrandMean Well
-
SeriesMPQ Series
-
Power Rating200 Watt
-
Output Voltage5 Volt
-
Rated Current12 Ampere
-
Input Voltage90V~264V
-
No of Output4
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length7 in
-
Width4.22 in
-
Height1.4 in
-
Weight1.46 lb
::specification::
Frequently Asked Questions
Can I use the MPQ-200B for equipment that needs several DC rails from one power supply?
This model is described as a 200W constant voltage power supply with 5V, 12V, -5V, and -12V outputs in the product name. That makes it relevant for systems that require multiple DC rails from one chassis supply rather than a single-output design. The main listed output is 5V at 12A, and the overall power rating is 200W.
Is the MPQ-200B suitable for industrial or embedded systems that use both positive and negative voltage rails?
It can suit embedded, industrial, or control equipment when the design calls for the 5V, 12V, -5V, and -12V rail combination named for this model. That is different from a standard single-output supply and is useful where multiple board-level rails are needed from one unit. Buyers should confirm their equipment requires the B version rail set specifically.
Would the MPQ-200B fit medical or electronic test equipment that needs low leakage current?
The unit is medical safety approved and specifies extremely low leakage current below 150 uA. Those characteristics can matter for medical and electronic equipment designs with tighter leakage requirements. The supply is rated for 200W and uses a wide 90-264VAC input range.
Can this power supply handle broader AC input conditions for OEM equipment?
The specified input range is 90-264VAC, which supports a broad AC input window for global equipment designs. For OEMs building equipment sold into different mains environments, that range reduces the need for a narrow-input supply. The output side remains a constant voltage multi-output design rated for 200W.
Is the MPQ-200B intended for outdoor or wide-temperature use?
The published operating temperature range is -20C to +70C, so the product data supports review for indoor equipment across that temperature span. No IP rating is listed in the provided specs, so the data does not establish outdoor, washdown, or weather-exposed use. The environmental guidance here is based on temperature only.
How does the MPQ-200B compare with the other MPQ siblings listed?
The listed siblings are MPQ-120B, MPQ-120C, MPQ-120D, MPQ-120E, MPQ-200C at 200W and 5V 12A, MPQ-200D at 200W and 5V 12A, and MPQ-200F at 200W and 5V 15A. The MPQ-200B is the 200W B version whose product name specifies 5V, 12V, -5V, and -12V outputs. Among the siblings with published ratings here, the main listed 5V output current is 12A for B, C, and D, while F is 15A.
