Mean Well RSP-1500-27 Power Supply 1512W 27V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RSP-1500-27 Power Supply 1512W 27V
The RSP-1500 is a 1500W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSP Series
-
Power Rating1512 Watt
-
Output Voltage27 Volt
-
Rated Current56 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty5 Year
-
Length10.94 in
-
Width5 in
-
Height3.29 in
-
Weight6.61 lb
::specification::
Frequently Asked Questions
What 27V DC systems justify using the RSP-1500-27?
The RSP-1500-27 delivers 27V at 56A (1512W) and is suited for high-current 27V bus applications such as industrial battery charger systems for 24V lead-acid strings, high-power telecommunications infrastructure, and industrial machinery with 27V specification rails. The 90–264VAC input covers all standard single-phase supply voltages.
Can the RSP-1500-27 be used in parallel for N+1 redundancy?
Yes. The RSP-1500-27 supports active current sharing (3+1). Three units in parallel deliver 168A at 27V, and a fourth unit provides N+1 hot standby with automatic load balancing.
How does the RSP-1500-27 compare to the RSP-1500-24 and RSP-1500-48?
RSP-1500 voltage variants: RSP-1500-5 (1200W/5V/240A), RSP-1500-12 (1500W/12V/125A), RSP-1500-15 (1500W/15V/100A), RSP-1500-24 (1512W/24V/63A), RSP-1500-27 (1512W/27V/56A), RSP-1500-48 (1536W/48V/32A). The RSP-1500-27 delivers 27V/56A/1512W, sharing the same chassis and ratings as the RSP-1500-24 except for the voltage and current difference. The RSP-1500-48 at 1536W is slightly higher wattage at a lower current.
What is the temperature range and IP status of the RSP-1500-27?
The RSP-1500-27 operates from -20°C to +70°C ambient. No IP ingress rating is provided, requiring the unit to be installed inside a sealed or filtered enclosure for dusty or wet environments.
What certifications does the RSP-1500-27 hold?
The RSP-1500-27 is certified to BSMI, CB, CE, EAC, TÜV, and UL. CCC (China) certification is not included in the RSP-1500 series.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other RSP-1500 Models
3 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well RSP-1500-24 Power Supply 1512W 24V | 1512W | 24V | 63A | Indoor | $395.02 | View |
| Mean Well RSP-1500-12 Power Supply 1500W 12V | 1500W | 12V | 125A | Indoor | $393.55 | View |
| Mean Well RSP-1500-48 Power Supply 1536W 48V | 1536W | 48V | 32A | Indoor | $351.55 | View |
