Mean Well ODLC-45-1050 Power Supply 45W 1050mA, Dimmable
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating45.15 Watt
-
Output Voltage43 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-1050 for a constant current LED downlight?
Yes, this driver is built for constant current LED loads at 1050mA. It works with downlight modules whose total forward voltage falls within the 26-43V constant current range and within the 45.15W rating.
Is this driver suitable for LED signage modules or a small LED array?
It can be used for signage modules or small LED arrays only when the load is a constant current 1050mA design. The total LED forward voltage must stay within 26-43V, because this is not a constant voltage power supply.
Can this power supply run a medium-voltage COB LED engine?
Yes, if the COB or LED engine is specified for 1050mA constant current operation. The driver regulates current at 1050mA and supports a 26-43V output range up to 45.15W.
How do I know if my LED load is compatible with this 1050mA driver?
Match the LED load to 1050mA constant current and make sure its total forward voltage is within 26-43V. The number of LEDs depends on each LED's forward voltage, so compatibility is based on the full series voltage rather than a fixed LED count.
Is the ODLC-45-1050 appropriate for wet or harsh environments?
This model is rated IP67 and operates from -20°C to +85°C, so it is suited to environments where waterproofing and a wide operating temperature range matter. Environmental suitability still depends on the rest of the fixture meeting the same conditions.
