Mean Well ODLC-45-1050DA Power Supply 45W 1050mA, DALI
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating45.15 Watt
-
Output Voltage43 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-1050DA with a 1050mA LED downlight module?
Yes, this is a constant current LED driver rated for 1050mA output. It is suitable when the downlight's total forward voltage falls within the 26-43V constant current range and the load stays within 45.15W.
Will this work for a signage light engine or compact LED array?
It can, but only if the light engine is designed for constant current operation at 1050mA. The connected LED load must also stay within the 26-43V output range, since this driver does not provide constant voltage output.
Is this driver a good fit for mid-power architectural LED modules?
It is a fit for architectural LED modules that require 1050mA constant current and fall within the 26-43V operating window. The available output power is 45.15W, so the module wattage must remain within that limit.
How should I check LED compatibility with the ODLC-45-1050DA?
Confirm that the LED module requires 1050mA constant current and that the total forward voltage is between 26V and 43V. The number of LEDs depends on each LED's forward voltage, so there is no single fixed LED count for this driver.
What is the difference between the ODLC-45-1050DA and the other ODLC constant current models?
Within the related series, the 1050mA models are 26-43V at 45.15W, the 1400mA models are 19-32V at 44.8W, the 700mA models are 38-64V at 44.8W, the 500mA models are 54-90V at 45W, and the 350mA models are 57-95V at 33.2W or 33.25W. The 65-series siblings step up to 65.1W at 1050mA with 46-62V, 64.4W at 1400mA with 34-46V, 63W at 1750mA with 27-36V, or 65.1W at 700mA with 69-93V.
