Mean Well ODLC-45-1400 Power Supply 45W 1400mA, Dimmable
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating44.8 Watt
-
Output Voltage32 Volt
-
Rated Current1.4 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-1400 for a high-current LED downlight?
Yes, this driver is intended for constant current LED loads at 1400mA. It fits downlight modules whose total forward voltage falls within 19-32V and whose power demand stays within 44.8W.
Is this suitable for a low-voltage COB LED array?
Yes, if the COB array is specified for 1400mA constant current operation. The driver supports a 19-32V constant current range, which makes it better suited to lower-voltage, higher-current LED loads than higher-voltage strings.
Can this driver power signage modules that need more current and less voltage?
It can be used for signage modules designed around 1400mA constant current. The total LED forward voltage must remain within 19-32V, and the load must stay within the 44.8W rating.
How do I verify compatibility with this 1400mA constant current driver?
The LED load must be rated for 1400mA constant current, and its combined forward voltage must fall within 19-32V. The number of LEDs depends on each LED's forward voltage, so compatibility is determined by total series voltage rather than a set LED quantity.
Can the ODLC-45-1400 be used in wet or temperature-variable locations?
This driver carries an IP67 waterproof rating and an operating temperature range of -20°C to +85°C. Those specs make it suitable for fixtures that need sealing and broad environmental tolerance.
