Mean Well ODLC-45-1400DA Power Supply 45W 1400mA, DALI
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating44.8 Watt
-
Output Voltage32 Volt
-
Rated Current1.4 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-1400DA with a 1400mA LED downlight module?
Yes, provided the downlight is a constant current load rated for 1400mA. Its total forward voltage needs to stay within the 19-32V constant current range, and total load must remain within 44.8W.
Is this driver suitable for compact signage modules or small COB arrays?
It is suitable for compact LED loads that are designed for 1400mA constant current operation. Because the output range is 19-32V, it fits lower-voltage LED arrays rather than higher-voltage series strings.
Can this model be used where a constant voltage LED power supply would normally be installed?
No, this is a constant current driver, not a constant voltage power supply. It regulates 1400mA across a 19-32V range, so the LED module must be specified for constant current operation.
How many LEDs can the ODLC-45-1400DA run?
That depends on each LED's forward voltage, not on a fixed LED count. The correct match is a 1400mA constant current LED load whose total forward voltage falls within 19-32V.
Is this model appropriate for damp, outdoor, or industrial fixture environments?
The ODLC-45-1400DA is rated IP67 and operates from -20°C to +85°C. Those specs support use in sealed fixtures exposed to water and broad ambient temperature conditions.
