Mean Well ODLC-45-350 Power Supply 45W 350mA, Dimmable
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating33.25 Watt
-
Output Voltage95 Volt
-
Rated Current0.35 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-350 for a high-voltage LED downlight string?
Yes, this model is suited to constant current LED loads at 350mA with a higher series voltage. Its constant current output range is 57-95V, with up to 33.25W available.
Is the ODLC-45-350 a good choice for long-series signage modules or linear LED arrays?
It can be a good fit when the signage modules or linear array are designed for 350mA constant current operation. The total LED forward voltage must fall within 57-95V, which makes it better matched to longer series strings than lower-voltage drivers.
Can this driver run small LED arrays that need lower current but more voltage?
Yes, if the array is specified for 350mA constant current and its total forward voltage is within 57-95V. The driver's 33.25W rating sets the upper power limit for the connected LED load.
How do I determine whether my LED module is compatible with the ODLC-45-350?
The LED module must require 350mA constant current, and the full LED string must fall within the 57-95V output range. The number of LEDs depends on each LED's forward voltage, so compatibility should be checked by total forward voltage instead of a specific LED count.
What should I compare when choosing between the ODLC-45-350 and other ODLC 45W models?
In the 45-series, the 350mA versions are 57-95V at 33.2W or 33.25W, the 500mA versions are 54-90V at 45W, the 700mA versions are 38-64V at 44.8W, the 1050mA versions are 26-43V at 45.15W, and the 1400mA versions are 19-32V at 44.8W. The main difference is the current rating paired with its corresponding constant current voltage window and power rating.
