Mean Well ODLC-45-350DA Power Supply 45W 350mA, DALI
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating33.2 Watt
-
Output Voltage95 Volt
-
Rated Current0.35 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-350DA for a high-voltage LED downlight module?
Yes, if the downlight uses a constant current driver at 350mA and the module's total forward voltage falls within the 57-95V constant current range. This driver is rated for 33.2W, so the LED load also needs to stay within that power level. It is a constant current model, not a constant voltage power supply.
Is this driver suitable for signage modules or small LED arrays that run at 350mA?
It can be a fit for signage modules or small LED arrays that are designed for 350mA constant current operation. The load must operate within the 57-95V output range, and the exact number of LEDs depends on the forward voltage of each LED in the array. It should not be used where the LEDs require a fixed constant voltage output.
Can the ODLC-45-350DA power an architectural LED fixture with DALI control?
Yes, when the fixture is built around a 350mA constant current engine and its forward voltage is within 57-95V. The product name identifies it as a DALI version, so it is intended for applications where that control method is required. Power draw still needs to remain within the 33.2W rating.
How do I know if this 350mA driver is compatible with my LED board?
Compatibility depends on two things: the LED board must require 350mA constant current, and its total forward voltage must land inside the 57-95V CC output range. The number of LEDs cannot be stated as a fixed count because it depends on each LED's forward voltage. If your board expects constant voltage instead, this is not the right type of driver.
Can this driver be used in wet or demanding environments?
The ODLC-45-350DA is rated IP67, so it is built for waterproof use where that enclosure rating is needed. It also has an operating temperature range of -20°C to +85°C, which supports use in hot or cold conditions within that window. Environmental suitability still depends on the rest of the fixture meeting the same conditions.
