Mean Well ODLC-45-700 Power Supply 45W 700mA, Dimmable
The ODLC-45 is a 45W Mean Well DIN rail power converter with a 111mm profile (input range: 90~295VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 111mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”) UL8750 BIS IS15885( for ODLC-45-700,1050,700DA,1050DA only), EAC TP TC 004,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesODLC Series
-
Power Rating44.8 Watt
-
Output Voltage64 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~295V
-
No of Output1
-
Dimming Control0-10V,10V PWM
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-20°C~85°C
-
Warranty3 Year
-
Length4.37 in
-
Width3.03 in
-
Height1.12 in
-
Weight0.93 lb
::specification::
Frequently Asked Questions
Can I use the ODLC-45-700 for a 700mA LED downlight engine?
Yes, if the LED engine is designed for 700mA constant current and its total forward voltage falls within 38-64V. This driver is rated for 44.8W, so the connected load needs to stay within that power level. It is not intended for constant voltage LED products.
Is this driver suitable for compact signage or illuminated panels using 700mA LEDs?
It can be suitable when the signage module or small LED array requires 700mA constant current input. The output voltage adjusts across 38-64V, and the number of LEDs depends on the forward voltage of each LED rather than a fixed count. That makes it a current-matched choice instead of a voltage-matched one.
Can the ODLC-45-700 power a small COB or multi-LED array?
Yes, for COBs or small LED arrays that are rated for 700mA constant current and operate inside the 38-64V CC range. The maximum output power is 44.8W, so the load must remain within that limit. This makes it more suitable for medium-voltage constant current arrays than high-voltage ones.
What makes an LED module compatible with this 700mA driver?
The LED module must be specified for 700mA constant current operation and fit within the 38-64V output window. The actual LED count varies with each LED's forward voltage, so compatibility cannot be determined by LED quantity alone. Constant voltage modules are not a match for this driver.
Can this driver handle indoor and outdoor exposure?
The ODLC-45-700 carries an IP67 waterproof rating, so it is intended for applications where that level of environmental sealing is needed. It also operates from -20°C to +85°C, which supports a broad range of installation conditions. Environmental fit should still be evaluated at the finished fixture level.
